Honeywell MK7120-31B41 MS7120 Orbit 7120 Omnidirectional Laser Barcode Scanner

Orbit 7120 Series Omnidirectional Laser Scanners Wireless Single-Line Laser Scanner MK7120 seriesHoneywell's Orbit® series of scanners provide aggressive omnidirectional scanning in an award-winning design for retailers seeking an affordable, aesthetically-pleasing scanning solution. Orbit, the all-time, best-selling hands-free omnidirectional scanner, presents an innovative, elegant and affordable solution for convenience retail applications where counter space is at a premium. Compact, lightweight and rugged, Orbit maximizes customer satisfaction and employee efficiency with a patented 20-line scan pattern, an easy-to-find sweet spot and a scan speed of 1, 120 scans per second.

Recipient of multiple design honors, Orbit's award-winning shape enables hand-held scanning of large, bulky items. For added flexibility, the scanning head can be tilted within a 30-degree range to accommodate objects of various sizes and shapes. For applications that require menu scanning, OrbitCG 7180 combines the power of patented CodeGate® technology with many of the outstanding features already found in the Orbit®
7120. CodeGate technology allows the user to easily target the desired bar code and complete data transmission with the push of a single button. The scanner's expanded ability to update its firmware via Honeywell's free patented MetroSet®2 configuration software safeguards longterm infrastructure commitments in the event of a change in the POS system or software. Standard features include an integrated EAS antenna for tag deactivation (OrbitCG 7180 only), power save mode, user-replaceable cables, Honeywell's patented MetroSelect and MetroSet®2 for easy configuration, data editing and OPOS/JPOS compatibility for easy installation. Features MK7120 series 20
Scan Line Omnidirectional Pattern: Provides aggressive scanning as an additional benefit to hand presentation applications
Sweet Spot Scanning: Engineered "sweet spot" to optimize scan performance and first pass read rate.
Adjustable Scan Head: Ability to tilt scanner 30 degrees for targeted scanning or larger products.
Flash ROM: Protects POS investment with free firmware updates via MetroSet®2 software and standard PC.
Automatic Scanning Operation: Simply present a bar code and the unit scans in a single pass. Built-in RF EAS
Antenna (Orbit 7180 only): Increases efficiency by simultaneously deactivating RF EAS tags and decoding bar codes Specifications.
Mechanical Dimensions (L x W x H): 4.1 x 4.0 x 5.9 inches (105 x 102 x 150mm)
Weight: 14.1 oz (400g)
Electrical Input Voltage: 5VDC ± 0.25V
Operating Power: 900mW (180mA @ 5V)
Standby Power: 850mW (170mA @ 5V) Host
System Interfaces: USB, RS232, Keyboard Wedge, IBM 468xx (RS485), Light Pen Wand Emulation
Environmental Operating Temperature: 32 - 104°F (0 - 40°C)
Storage Temperature: -40 - 140°F (-40 - 60°C)
Humidity: 5% to 95% relative humidity, non-condensing
Drop: Designed to withstand 4-foot ( 1.2 m) drops
Environmental Sealing: Sealed to resist airborne particulate contaminants
Light Levels: 4842 Lux Scan Performance Scan
Pattern Omnidirectional: 5 fields of 4 parallel lines
Button-activated single line: (7180)
Scan Speed Omnidirectional: 1120 scan lines per second
Single line: 56 scan lines per second (7180)
Print Contrast: 35% Minimum reflectance difference Pitch x Skew 60 degrees x 60 degrees
Decode Capabilities: Reads standard 1D and GS1 DataBar symbologies
