MEAN WELL LRS-350-12 348W 12V 29 Amp Single Output Switchable Power Supply (LRS-350-12)

348W 12V 29A Single Output Switchable Power Supply 12 Volts 29 Amps Features • AC input range selectable by a switch • Withstand 300 VAC surge input for 5 seconds • No load power consumption • 1U low profile • High operating temperature, up to 70°C •
Protections: Short circuit / Overload / Over voltage / Over temperature • Built-in cooling fan, ON-OFF control • Compliance to UL 60950-1 • Withstand 5G vibration test • High efficiency, long life and high reliability • LED indicator for power on • 100% full load burn-in test • 3 year warranty Applications • Industrial automation machinery • Industrial control system • Mechanical and electrical equipment • Electronic instruments, equipment or apparatus Related Products • LRS-350- 3.3 ( 3.3V 60A, 198W)
Jameco P/N: 2219778 • LRS-350- 4.2 ( 4.2V 60A, 252W)
Jameco P/N: 2219786 • LRS-350-5 (5V 60A, 300W)
Jameco P/N: 2219794 • LRS-350-15 (15V 23.2A, 348W)
Jameco P/N: 2219815 • LRS-350-24 (24V 14.6A, 350.4W )
Jameco P/N: 2219823 • LRS-350-36 (36V 9.7A, 349.2W )
Jameco P/N: 2219831 • LRS-350-48 (48V 7.3A, 350.4W )
Jameco P/N: 2219840 • LRS-150 Series (150 Watt, Enclosed Switchable Single Output Power Supply) • LRS-150F Series (150 Watt, Full Range Input Enclosed Switching Power Supply) • LRS-200 Series (200 Watt, Enclosed Switchable Single Output Power Supply) Detailed Specifications: • Primary
Output Voltage (VDC): 12 •
Output Current (A): 29 • Maximum
Output Power (W): 350 •
Family: LRS-350 •
Input Voltage (VAC): 90 to 132, 180 to 264 •
Input Frequency: 47 to 63 •
Maximum Input Current (A): 6.8 •
Output Connector Type: Screw Terminal Block • Number of
Outputs: 1 •
Product Type: AC to DC Power Supply (more. ).
