SFP+ Modul Supplier 1260--1610nm 10G 80km LC ESD Parts Box 3 Years Fiber Optic Transceivers Avago MAXIM Sumitomo

Product Description
UT-KING SFP+ER transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 80km.
The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a PIN photode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
PRODUCT FEATURES
* Compliant with SFF-8431, SFF-8432 and IEE 802.3 ae
Cooled EML transmitter and PIN receiver
Wavelength selectable to ITU-T standards covering grid wavelengths Digital Diagnostic Monitor Interface
Hot pluggable
link length up to 80km
10GBASE-ER, and 2G/4G/ 8G/10G Fiber Channel applications.
Low power consumption
Operating case temperature: 0 to 70 C
Networks
APPLICATIONS
* 10GBASE-LR at 10.3125G bps
* Other optical links
* 10G Ethernet
Specification
item
value
Model Number
SFP-10G--80
Type
Fiber Optic Transceivers
Network
None
Product name
80km 10G SFP
Max Cable Distance
10km/20km/40km/80km
Data rate
10G
Wavelengh
1260-1610nm
Chipset
Avago MAXIM Sumitomo
Warranty
3 Years
Name
80km 10g sfp
Packing
ESD Parts Box
Optical Connector
LC
No. of Fiber
1
