40Gbps QSFP+ SR4 optical module QSFP-40G-SR4Juniper Compatible 40GBASE-SR4 for Switch

Product Description
The 40GBASE QSFP+ (Quad Small Form-Factor Pluggable Plus) modules offer customers a wide variety of high-density 40 Gigabit
Ethernet connectivity options for data center, high-performance computing networks, enterprise core and distribution layers, and
service provider transport applications.
The 40GBASE-SR4 QSFP+ Module supports link lengths of 100m and 150m respectively on laser-optimized OM3 and OM4 multimode fiber
cables. It primarily enables high-bandwidth 40G optical links over 12-fiber ribbon r cables terminated with MPO/MTP multi-fiber
connectors. It can also be used in 4x10G mode along with ribbon to duplex fiber breakout cables for connectivity to four
10GBASE-SR optical interfaces. Maximum channel insertion loss allowed is respectively 1.9 dB over 100m of OM3 cable or 1.5 dB over
150m of OM4 cable.
Features
* 40GBASE-SX Quad Small Form-factor Pluggable Plus (QSFP+).
* Standards based 40-Gigabit Ethernet (40GBASE-SR).
* 40 Gbit/sec line speed.
* Operating distance up to 150m on OM4 fibre.
* Transmitter wavelength 850nm.
* Industry-standard MPO connector.
* Multimode Fibre (MMF).
* Digital Optical Monitoring (DOM).
Form Factor
QSFP+
Data Rate
41.2G bps
Wavelength
4 lanes, 840nm to 860nm
Distance
150 meters (492 feet)
Operating Temperature Range
Commercial 0C to 70C
Storage Temperature Rrange
-40 to 85C
Digital Diagnostics (DDM)
