Good price fiber optic mux high quality 1+8 channel demux

8+1550 Channel MUX/DEMUX with LC/UPC
(1470nm, 1490nm, 1510nm, 1530nm, 1550nm, 1570nm, 1590nm, 1610nm)
1.
FEATURES:
Low PDL
High Isolation
Compact Design
Low Insertion Loss
8 Channels Mux/Demux(2~18 channels Optional)
Good channel-to-channel uniformity
High Reliability and Stability
Compliant to ITU-T G. 657A1 standard
Wide Operating Wavelength: 1471nm to 1611nm(1261nm~1611nm)
Wide Operating Temperature: -5~75
2.
APPLICATIONS:
System
PON Networks
CATV Links
3.
COMPLIANCE:
Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
RoHS
4.
SPECIFICATIONS:
1N Mux/Demux Module
Parameter
4 Channel
8 Channel
18 Channel
Mux
Demux
Mux
Demux
Mux
Demux
Channel Wavelength (nm)
1270~1610
Center wavelength Accuracy (nm)
0.5
Channel Spacing (nm)
20
Channel Passband (@- 0.5 dB bandwidth (nm)
>13
Insertion Loss (dB)
1.6
2.5
3.0
Channel Uniformity (dB)
0.6
1.0
1.5
Channel Ripple (dB)
0.3
Isolation (dB)
Adjacent
N/A
>30
N/A
>30
N/A
>30
Non-adjacent
N/A
>40
N/A
>40
N/A
>40
Inertion Loss Temperature Sensitivity (dB/C)
<0.005
Wavelength Temperature Shifting (nm/C)
<0.002
Polarization Dependent Loss (dB)
<0.1
Polarization Mode Dispersion
<0.1
Directivity (dB)
>50
Return Loss (dB)
>45
Maximum Power Handling (mW)
300
Opterating Temperature (C)
-5~+75
Storage Temperature (C)
-40~85
Package dimension (mm)
L100 x W80 x H10 or L140xW100xH15
