$129.99
Meet Your Seller
Neutrik NKO12SA-L-0-92 OpticalCON DUO 2-Channel Singlemode Fiber Cable 92m / 300ft
- Target Application: Professional broadcast, touring AV, live event production, and field deployments requiring ruggedized, high-bandwidth fiber connectivity over long distances.
- Factory-Assembled 92-Meter Cable: Pre-terminated 92-meter (approx. 302 feet) opticalCON DUO fiber optic cable assembly delivered ready for immediate plug-and-play field deployment.
- 2-Channel Singlemode (APC) Optics: Premium 2-core singlemode APC (Angled Physical Contact) optical fibers ensure exceptionally low insertion loss and high return loss across long runs.
- Ruggedized Field Construction: Tactical armored cable jacket with aramid yarn strain relief provides superior crush resistance, high tensile strength, and extreme flexibility.
- Dirt & Dust Protection: Features a automatic sealing shutter system in the connector housing that seals glass optics against dust, dirt, and moisture when disconnected.
- Standard LC Compatibility: Compatible with conventional LC connectors on the rear chassis side using standard adapter interfaces.
- IP65 Weather Resistance: IP65 water- and dust-resistant rating when mated with opticalCON DUO chassis connectors, ensuring reliable performance in harsh outdoor environments.
+
+
Overview
Specs
Reviews
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
The Neutrik NKO12SA-L-0-92 is a factory-assembled, 92-meter (approx. 302 ft) heavy-duty 2-channel singlemode fiber optic cable built for high-demand broadcast, touring AV, and field production applications. Featuring Neutriks renowned opticalCON DUO connector system, this assembly combines the ruggedness of an industrial metal housing with the ultra-low signal attenuation of premium APC (Angled Physical Contact) singlemode optics.
Designed to withstand the rigors of live event production and harsh outdoor environments, the NKO12SA-L-0-92 utilizes a flexible, aramid-reinforced tactical field cable with superior crush and tensile resistance. The integrated automatic shutter system covers and protects the internal optical interfaces against dirt, dust, and moisture whenever the cable is disconnected, ensuring consistent, low-loss optical signal transmission across long-distance broadcast setups.
Key Features & Highlights- Factory-Terminated 92m Length: Pre-built 92-meter (301.8 ft) heavy-duty cable assembly ready for immediate deployment in mobile broadcast vans, live arenas, and outdoor venues.
- 2-Channel Singlemode APC Optics: Premium 2-core singlemode fibers with APC (Angled Physical Contact) polishing deliver optimal return loss and minimal insertion loss over long cable runs.
- Ruggedized Metal Housing: All-metal opticalCON DUO connector bodies featuring a robust push-pull locking mechanism prevent accidental disconnects during high-intensity field use.
- Automatic Sealing Shutters: Built-in dust and dirt protection shutters automatically seal the optical ferrule faces when unmated, eliminating the need for tedious manual protective caps.
- Tactical Aramid Reinforcement: Heavy-duty black outer jacket reinforced with high-tensile aramid yarn provides extreme flexibility, abrasion resistance, and crush protection.
- IP65 Rated Environmental Protection: Achieves IP65 dust and water resistance when mated with matching opticalCON DUO chassis connectors (NO2-4FDW series).
- Standard LC Interface Compatibility: Rear chassis side connects cleanly to standard LC optical duplex patch cords for straightforward integration into existing rack panels and fiber infrastructure.
| SpecificationDetails | |
| Manufacturer Part Number | NKO12SA-L-0-92 |
| Product Series | Neutrik opticalCON DUO |
| Connector Type | opticalCON DUO Heavy Duty (Male to Male) |
| Fiber Type / Core Count | Singlemode APC (Angled Physical Contact) / 2 Cores (9/125 µm) |
| Cable Length | 92 Meters (301.8 Feet) |
| Outer Cable Diameter | 5.0 mm (0.2 in) |
| Insertion Loss | < 0.45 dB per connector |
| Return Loss | > 60 dB (APC) |
| Tensile Performance | High-tensile strain relief with integrated aramid yarn |
| Environmental Protection | IP65 Weather-resistant (Mated) |
| Operating Temperature Range | 40C to +75C (40F to +167F) |
| Cable Net Weight | ~4.4 lbs (2.0 kg) |
| Boxed / Shipping Weight | ~5.5 to 6.2 lbs (~2.5 to 2.8 kg) |
| Packaging Dimensions | ~14.0 × 14.0 × 6.0 in (~35.6 × 35.6 × 15.2 cm) |
| Country of Origin | Liechtenstein |
- Neutrik opticalCON DUO 2-Channel Singlemode Fiber Assembly (92m / NKO12SA-L-0-92)
- Protective Rubber Connector End Covers
- Factory Optical Test Report & Inspection Certificate
