2.13inch Touch e-Paper Display for Raspberry Pi Zero 2 W/Raspberry Pi Zero/Pi Ze
- 2.13" capacitive touch e-Paper display, 5-point touch, 250×122 pixels.Display color: black, white. Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi Zero / Zero W. Supports waken up by user-defined gesture
- No backlight, keeps displaying last content for a long time even when power down. Ultra low power consumption, basically power is only required for refreshing. Heat dissipation holes on the back,combined with thermal tape, effective heat dissipation
- Outline dimensions(Module): 69.15 × 38.90mm. Outline dimensions(Driver Board): 59.51mm × 34.00mm. Display area: 48.55mm × 23.71mm. Operating Voltage: 3.3V (V1.1 support 5V). Communication interface: SPI. Dot pitch: 0.194 × 0.194mm
- Greyscale: 2. Partial refresh time: 0.3s. Full refresh time: 2s. Refresh power: 26.4mW(typ.). Touchpoints: 5 (MAX). Touch type: Capacitive touch. Touch interfaced: I2C. Touch panel: Toughened Glass
- Comes with development resources and manual (examples for Raspberry Pi)
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
2.13" capacitive touch e-Paper display, 5-point touch, 250×122 pixels.
Display color: black, white. Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi Zero / Zero W. Supports waken up by user-defined gesture
No backlight, keeps displaying last content for a long time even when power down. Ultra low power consumption, basically power is only required for refreshing. Heat dissipation holes on the back, combined with thermal tape, effective heat dissipation
Outline dimensions (Module): 69.15 × 38.90 mm. Outline dimensions (Driver
Board): 59.51 mm × 34.00 mm.
Display area: 48.55 mm × 23.71 mm.
Operating Voltage: 3.3V (V 1.1 support 5V).
Communication interface: SPI.
Dot pitch: 0.194 × 0.194 mm
Greyscale:
2.
Partial refresh time: 0.3 s.
Full refresh time: 2s.
Refresh power: 26.4 mW(typ. ).
Touchpoints: 5 (MAX).
Touch type: Capacitive touch.
Touch interfaced: I2C.
Touch panel: Toughened Glass
Comes with development resources and manual (examples for Raspberry Pi)
Display color: black, white. Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi Zero / Zero W. Supports waken up by user-defined gesture
No backlight, keeps displaying last content for a long time even when power down. Ultra low power consumption, basically power is only required for refreshing. Heat dissipation holes on the back, combined with thermal tape, effective heat dissipation
Outline dimensions (Module): 69.15 × 38.90 mm. Outline dimensions (Driver
Board): 59.51 mm × 34.00 mm.
Display area: 48.55 mm × 23.71 mm.
Operating Voltage: 3.3V (V 1.1 support 5V).
Communication interface: SPI.
Dot pitch: 0.194 × 0.194 mm
Greyscale:
2.
Partial refresh time: 0.3 s.
Full refresh time: 2s.
Refresh power: 26.4 mW(typ. ).
Touchpoints: 5 (MAX).
Touch type: Capacitive touch.
Touch interfaced: I2C.
Touch panel: Toughened Glass
Comes with development resources and manual (examples for Raspberry Pi)
