20pcs Reed Switch Normally Open 2x14mm Magnetic Switch MKA14103 2 * 14mm Normally Open Magnetic Induction Switch Glass Seal with Gold Plated Pin
Limited time offer, ends 08/23 By LUOYIMAN
- 2*14mm Normally Open Reed Switch; Normally Open Reed Switch Magnetic Switch; Glass Sealed with Gold Plated Pin; High quality and High Sensitivity
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Description:
Name: Reed
Switch Type: Normally
Open Glass Length: 14mm
Glass Diameter: 2mm
Total Length: 45mm
Contact Form: A Max.
Switching Voltage: 300V DC Min.
Breakdown Voltage: 150V DC Max.
Contact Rating: 10W Max.
Switching Current: 0.55 A Max.
Operate time: 0.45 ms
Bounce time: 0.25 ms Max.
Release time: 0.35 ms
Resonant Frequency: 5000 HZ Max.
Operating Frequency: 400 HZ Pull in
Value: 20-70 AT Min.
Drop out Value: 4AT Max.
Contact Capacitance: 0.5 pF
Electrical Life: 50mV-10uA-1x10
Package included: 20 x Normally Open Reed Switch 2x14mm
Name: Reed
Switch Type: Normally
Open Glass Length: 14mm
Glass Diameter: 2mm
Total Length: 45mm
Contact Form: A Max.
Switching Voltage: 300V DC Min.
Breakdown Voltage: 150V DC Max.
Contact Rating: 10W Max.
Switching Current: 0.55 A Max.
Operate time: 0.45 ms
Bounce time: 0.25 ms Max.
Release time: 0.35 ms
Resonant Frequency: 5000 HZ Max.
Operating Frequency: 400 HZ Pull in
Value: 20-70 AT Min.
Drop out Value: 4AT Max.
Contact Capacitance: 0.5 pF
Electrical Life: 50mV-10uA-1x10
Package included: 20 x Normally Open Reed Switch 2x14mm
