HTi HT-A10 Thermal Imaging Camera 252 x 192 IR Resolution 25Hz Thermal Imaging
- Features
- Thermal Imaging|High Resolution Imaging:Capture detailed thermal images with 252x192 resolution, ensuring precise temperature readings.
- Wide Temperature Range:Measure temperatures from -20 to 450, suitable for diverse applications.
- Adjustable Emissivity:Customize emissivity settings from 0.01 to 1.00 for accurate readings on various surfaces.
- Portable Design:Lightweight at 588g and compact, this thermal imager is easy to carry for on-site inspections.
- Built-in WiFi:Connect seamlessly with the HTI HT-A10's built-in WiFi for wireless data transfer and analysis.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Specifications
| Model | HT-A10 |
| Measuring Range | -20~450(-4~842) |
| Accuracy | 100:±2,100~300:±2%,300:±3% |
| Accuracy | -15~550±2 or ±2%,- 20~-15±4 |
| IR Resolution | 256x192 |
| LCD Resolution | 320x240 |
| Visible light image resolution | 640x480 |
| Field Of View Angle/Focal Length | 56°x42°/ 3.2mm |
| Spatial Resolution | 3.75 mrad |
| Pixel Size | 12m |
| Frame Rate | 9Hz |
| Focus Mode | Regular |
| NETD lens Focal Length | 70mK @25,@F/1.0mm |
| Wavelength Range | 8-14m |
| Emissivity | 0.01~1.00 Adjustable |
| Color palette mode | Rainbow, Iron Red, Cool Color, White Heat, Black Heat |
| Software analysis and recording functions | YES |
| WIFI | YES |
| Settings Control | Unit adjustment, language, date and time, proactive shutdown |
| Languages: | Chinese, English, German, Italian |
| Storage: | 8GB of built-in storage (approximately 6.6GB actually available) |
| Interface type: | Type-C |
| Battery type: | Built in 26650 rechargeable lithium battery |
| Battery capacity: | 5000mAh |
| Working Temperature | 0~45 |
| Storage Temperature | -20~60 |
| Humidity | 10% to 85% RH (non condensing) |
| Working Hours | 3~4hours |
| Size | 248mm×97mm×122.8mm |
| Weight | 588g |
