HTI HT-06 256x192 Pixels WIFI Transmission Handheld IR Thermal Imager Camera
- HTi Infrared Thermal Imager HT-06 256*192 Pixels WIFI Transmission Thermal Imaging Camera -20~550°C Handheld Wall Pipe Tester
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Specifications
| Model Number | HT-06 |
| Display Screen | 2.8 "Color Screen |
| Thermal image resolution | 256×192 |
| Visible Light Image Resolution | 640×512 |
| LCD Resolution | 320×240 |
| Measuring Range | -20 ~ 550(-4°F ~ 1022°F) |
| Accuracy | ±2% digital/±2 |
| Frame | 25Hz |
| Emissivity | 0.1-1.0 Adjustable |
| Pixel Spacing | 12m |
| IFOV (spatial resolution) | 3.75mrad |
| Software analysis and recording functions | YES |
| Palette | Rainbow/Iron Red/Cool/White Heat/Black Heat |
| Focus Mode | Fixed |
| File Format | JPG/MP4 |
| Image Storage | SD card (3G) |
| Thermal Sensitivity | 0.07 |
| Field angle/ focus length | 56°× 42°/ 3.2mm |
| Set Control | Localizationunit adjustment/Language/Date time format/Automatic shutdown |
| Focusing mode | Fixed |
| NETD | <50mK @ F#1.0 |
| Wavelength coverage | 8~14m |
| Battery | 3.7V rechargeable lithium-ion polymer battery |
| Working Hours | 2-3 hours |
| Size | 96×72×226mm |
| Battery Capacity | 2000mAh |
| Relative Humidity | 10% RH ~ 80 % RH |
| Interface Type | Micro USB 2.0 |
| Product Weight | 375g |
| Type | Built in 18650 rechargeable lithium battery |
