UNI-T UTL1020S 200W High-Resolution Programmable DC Electronic Load

The UNI-T UTL1020S is a 200 W programmable DC electronic load that delivers the highest measurement resolution in the UTL1000S series 0.01 mV and 0.01 mA for engineers who demand the finest measurement granularity from their bench equipment. With voltage ratings up to 150 V and current capacity to 30 A, the UTL1020S handles a wide range of power supply, charger, battery, and DC-DC converter validation tasks. 200 W Load Capacity - Handles up to 150 V / 30 A for testing power supplies, chargers, batteries, and DC-DC converters 0.01 mV / 0.01 mA Resolution - Highest resolution in the UTL1000S series for precision measurements and tight tolerance testing 4.3 -Inch TFT Color LCD - Large color display with live waveforms and ripple data a major upgrade over the basic VFD text displays found on competing loads 50 kHz Dynamic Mode - Up to 5× faster transient testing than competing loads in this class, which typically top out at 1025 kHz 15 Test Modes - Four more dedicated modes than competing loads, including OVP, time, load effect, short circuit, and combination modes Built-in Waveform & Ripple Measurement - Real-time voltage and current waveforms with Vpp/Ipp display a capability no competing load in this class offers 3 A/µs Maximum Slew Rate - 2× to 3× faster current transitions than typical competing loads for more realistic transient simulation 200-Step Programmable Auto List - More t Ships from authorized US dealer with 5-year warranty (3 years standard + 2 years with free registration)
