UNI-T UPO7104L Lab-Grade 1 GHz 4-Channel Rack-Mount Oscilloscope

The UPO7104L is a 1 GHz, four-channel digital storage oscilloscope in a 1U headless rack-mount form factor, engineered for high-density ATE rack integration and multi-instrument system test. With 10 GSa/s real-time sample rate (single-channel; 5 GSa/s dual; 2.5 GSa/s full four-channel), 1 Gpts of acquisition memory at single-channel mode (250 Mpts at full four-channel), UltraAcq waveform mapping at 600, 000 wfms/s standard (2, 000, 000 wfms/s in Sequence mode), and external display via HDMI plus full WebServer browser-based remote control over LAN, the UPO7104L is an eight-in-one bench platform consolidating oscilloscope, spectrum analyzer, DVM, frequency counter, AWG, multi-bus protocol analyzer, power analyzer, and jitter analyzer with eye diagram (some functions require optional license unlocks see Detailed Features below).

For ATE system integration, multi-instrument bench rack consolidation, high-channel-count parallel test, and engineering-validation environments where a 1U headless oscilloscope solves a rack-density problem that benchtop scopes cannot, the UPO7104L is the entry SKU into UNI-Ts UPO7000L line. Calculated rise time of 350 ps resolves leading-edge content on wide-bandgap (GaN, SiC) switching devices and high-speed digital interface characterization. Selectable 50 / 1 M inputs (1 M caps at 500 MHz) bring RF-grade signal-chain options to the same channel front end. Multi-machine synchronization up to 128 units / 512 channels supports parallel test architectures where benchtop scopes hit a channel-count ceiling.
