UNI-T UTG4164X 160 MHz 4Ch Performance-Series Arbitrary Waveform Generator

The UNI-T UTG4164X is the mid-range sweet spot of the UTG4000X Performance Series160 MHz sine wave output across four equal-performance channels, 2.5 GSa/s sampling, 16-bit resolution, and 128 Mpts waveform memory.
That frequency headroom matters: 160 MHz covers the clock rates and carrier frequencies of high-speed embedded systems, intermediate-frequency (IF) signal chains, and VHF-range wireless protocols that 100 MHz instruments can't reach, while the 80 MHz square wave and pulse output handles fast digital timing and gate drive simulation that lower-bandwidth models leave on the table. 160 MHz Sine / 80 MHz Square & Pulse Covers IF signal chains, VHF protocols, and high-speed clocking that 100 MHz generators can't reach. 80 MHz square and pulse output with sub-2 ns edge times handles fast digital timing characterization that matters for modern embedded designs. Four Independent Equal-Performance Channels Every channel delivers full 160 MHz sine and 80 MHz square/pulse capability. No primary/secondary channel compromisesfour complete signal sources in one instrument at a price where competitors offer two. 2.5 GSa/s Sampling with 16-Bit Resolution 65, 536 amplitude levels produce lower quantization noise than 14-bit competitors. Combined with -130 dBc/Hz phase noise (typical), the UTG4164X generates signals clean enough that the generator won't limit your measurement quality. 128 Mpts Arbitrary Waveform Memory Store and reproduce long, complex waveforms at full fidelity with point-by-point output mode.

Import custom. bsv/. csv waveform files via USB or load Ships from authorized US dealer with 5-year warranty (3 years standard + 2 years with free registration)
