Intel E10GSFPSR Compatible 10GBASE-SR SFP+ Transceiver Module, 850nm MMF, 300m, LC, DOM
- Direct replacement for the Intel E10GSFPSR 10GBASE-SR SFP+ module
- Coded and tested in Intel X520, X710, and other 10G Ethernet server adapters
- Compliant with SFP+ MSA, IEEE 802.3ae, SFF-8431, SFF-8432, and SFF-8472
- 300m reach on OM3, 400m on OM4, and 82m on OM2 multimode fiber
- Digital Optical Monitoring built in for real-time link diagnostics
- VCSEL transmitter with PIN receiver at 850nm
- Power draw under 1 W
- LC duplex connector, hot-pluggable
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Intel E10GSFPSR Compatible 10GBASE-SR SFP+ Transceiver Module (MMF, 850nm, 300m, LC, DOM)
This Intel E10GSFPSR compatible SFP+ transceiver carries 10GBASE-SR and 10GBASE-SW traffic over multimode fiber at 850nm through an LC duplex interface, reaching 300 meters on OM3, 400 meters on OM4, and 82 meters on older OM2. That covers the run from a server to top-of-rack or to an aggregation switch, which is where most Intel adapter links terminate.
Intel adapters are among the stricter platforms for optics acceptance, so each unit is programmed with Intel EEPROM coding and tested in Intel 10G server adapters and network interface cards before it ships, and the port recognizes it exactly as it would the OEM E10GSFPSR. Built-in Digital Optical Monitoring reports temperature, voltage, and optical power in real time, and the module meets the SFP+ MSA, SFF-8431, SFF-8432, and IEEE 802.3ae standards for clean interoperation with whatever sits at the far end.
Specifications
| Compatible OEM Part# | E10GSFPSR | Manufacturer Part# | FOD-INT-E10GSFPSR |
| Form Factor | SFP+ | Data Rate | 10 Gbps |
| Wavelength | 850 nm | Media Type | MMF |
| Max Distance | 82m @ OM2, 300m @ OM3, 400m @ OM4 | Transmitter Type | VCSEL |
| Receiver Type | PIN | Transmitter Power | -6 ~ -1 dBm |
| Receiver Sensitivity | < -10 dBm | Extinction Ratio | > 3.5 dB |
| Receiver Overload | > 0.5 dBm | Connector | LC Duplex |
| Power Consumption | 1 W | DDM/DOM | Yes |
| Compliance | RoHS, CE, REACH, SFP+ MSA, IEEE 802.3ae, SFF-8431, SFF-8432, SFF-8472 | Environment | Operating Temperature: 0~70°C, Storage Temperature: -40~85°C |
| Application | 10GBASE-SR/10GBASE-SW Ethernet, 10G fiber channel, 10G data center switches and routers, 10G network interface cards, 10G fiber media converters | Shipping Weight | 0.03 kg |
| Dimensions (LxWxH) | 56.7×13.7×8.5 mm | ||
