1.25G Gigabit Ethernet SFP to RJ45 Fiber Media Converter, 10/100/1000M RJ45 to 1000M SFP Slot, Fiber to Ethernet Converter, Supports 1000BASE-SX/LX LC Transceiver Module
- Optical Port: 1.25Gbps, support Gigabit Ethernet SFP modules and extends fiber distance up to 550m via OM3/OM4 multimode and 20km via OS2 single mode fiber optical cable.; RJ45 Port: UTP CAT5 10M/100M/1000M, Full Duplex or Half Duplex; Supports MDI/MDI-X auto crossover.; Complies with IEEE IEEE 802.3/802.3u/802.3z/802.3ab.; Status LED's for TX, FX LINK/ACT, POWER, FDX to easily monitor network status.; Supports jumbo frame size 9K bytes; Supports working temperature range from 0?C to 60?C; Support wide power supply voltage (100V-240V), operating voltage is 5VDC 1.0A.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Product description The Media Converter complies with IEEE 802.3 z, IEEE 802.3AB Standards. It is designed to convert data signal between 10/100/1000Base-T and 1000Base-LX Gigabit Ethernet. It supports 10/100/1000Base-T and 1000Base-LX applications.
Optical Port?
Connector: SFP Socket
Speed Rate: 1.25G
Wavelength: 850nm/1310nm/1490nm/1550nm
Fiber Type: MMF, SMF, Bi-di
Distance: 550m~120km
Ethernet Port Connector: RJ45
Speed Rate: 10/100/1000M auto-negotiation
Input Voltage: AC100V~240V or DC36~72V, 50/60Hz
Output Voltage: 5V1A
Connector: DC Socket Strong anti-interference ability Lightning protection Extend or bridge networks cost-effectively using fiber cabling Provide connectivity to users in an isolated area of a large complex or in a separate building 10/100/1000Mbps auto-sensed, easily upgrade Full-duplex and half-duplex auto-sensed MDI/MDI-X Auto Negotiation 10/100/1000Mbps store-and-forward Open SFP slot lets you customize your connection mode or distance using most MSA-Compliant transceivers. It can use different 1.25G SFP Transceivers according to the requirement, for
example: 1000Base-T, 1000Base-SX, 1000Base-LX etc.
FX: Light on when fiber speed is 1000Mbps, else light off
TX: Light on when TP speed is 1000Mbps, else light off
Link/ACT: Left side is indicate for fiber port link/act and right side for TP, light flashing when data transmitting and receiving
FDX: Light on when TP full-duplex mode is active, light off when TP half-duplex mode is active
PWR: Light on when DC power on, else light off See More
Optical Port?
Connector: SFP Socket
Speed Rate: 1.25G
Wavelength: 850nm/1310nm/1490nm/1550nm
Fiber Type: MMF, SMF, Bi-di
Distance: 550m~120km
Ethernet Port Connector: RJ45
Speed Rate: 10/100/1000M auto-negotiation
Input Voltage: AC100V~240V or DC36~72V, 50/60Hz
Output Voltage: 5V1A
Connector: DC Socket Strong anti-interference ability Lightning protection Extend or bridge networks cost-effectively using fiber cabling Provide connectivity to users in an isolated area of a large complex or in a separate building 10/100/1000Mbps auto-sensed, easily upgrade Full-duplex and half-duplex auto-sensed MDI/MDI-X Auto Negotiation 10/100/1000Mbps store-and-forward Open SFP slot lets you customize your connection mode or distance using most MSA-Compliant transceivers. It can use different 1.25G SFP Transceivers according to the requirement, for
example: 1000Base-T, 1000Base-SX, 1000Base-LX etc.
FX: Light on when fiber speed is 1000Mbps, else light off
TX: Light on when TP speed is 1000Mbps, else light off
Link/ACT: Left side is indicate for fiber port link/act and right side for TP, light flashing when data transmitting and receiving
FDX: Light on when TP full-duplex mode is active, light off when TP half-duplex mode is active
PWR: Light on when DC power on, else light off See More
