6x2 HDMI Matrix PIP 1.4V 4K*2K 3D Audio EDID/ARC/Audio Extractor 5.1CH Switch Splitter 6 Input 2 Output Converter For HDTV 06M1

The accessories with the machines lists as picture: 1.5V power adapter 1pcs2. Remote 1pcs3. User manual 1pcs
SPECIFICATIONS: HDMX0006M1HDMI resolution.............................. 4KX2K/3D/1080p/1080i/720p/576p/576i/480p/480iSupport HDMI audio format............................... DTS-HD/Dolby-true
HD/LPCM/DTS/Dolby-AC3/DSD
Digital Audio Output Supported Audio Format........................... LPCM 2.0 /Dolby AC3/ DTS
Digital Audio Output Sampling Rate........................ 32KHz, 44.1KH z, 48KHz, 88.2KH z, 96KHz, 176.4KH z, 192KHzMaxtransmission bandwidth...................................................................... 300MHzMax baud rate.................................................................................

....... 9.0G bps
Input/Output TMDS signal............................................................... 0.5 ~ 1.5V olts p-pInput/Output DDC signal................................................................. 5Volts p-p (TTL) Input cable distance......................... 10m (1080P) /5M (4K) AWG26 HDMI standard cable
Output cable distance....................... 15m (1080P) /5M (4K) AWG26 HDMI standard cable
Max working current.................................................................................... 700mAPower adapter format....................
Input: AC (50HZ, 60HZ) 100V-240V;
Output: DC5V/2AOperating Temperature range..................................................................... -0 to +40Storage Temperature range..................................................................... -20 to +60Operating Humidity range............................................. 5 to 85%RH (No Condensation) Storage Humidity range.

............................................... 5 to 95%RH (No Condensation) Dimension (L x W x H).................................................................. 205x74x26 (mm) Weight..............................................................................

............................ 440g The 6x2 HDMI Matrix supports the feature of PIP, ARC, 4K and 3D, which can switch or splitter the six HD input sources to the two HD Displays. It also can do the audio extract by the Optical port or HP port. ARC feature can let you return your TV audio to the av receiver; the PIP feature can let you choose the input sources channel by watch the small picture window at the Display. FEATURES
Six HDMI Inputs switch or split to two HD Displays. HDMI supports Full HD, 3D and 4Kx2K video
Any input HD Source can do audio extract by the SPDIF or 3.5 mm Headphone audio output port. HDMI to achieve the synchronization of audio signal separation. Support 2.0 / 5.1 / ADV three kinds of audio mode options
Supports ARC, TV audio will return and out by the Optical Port; (only the OUT A port supports ARC function). Supports HDMI audio separation, can output by optical and 3.5 mm Headphone at the same time
Support SPDIF digital audio format: Dolby digital (AC3), DTS and LPCM 2.0S upport
PIP function: have one main picture and five small pictures, it can do switch of input sources by press button or remot
