Din Rail 3 Phase 4 Wire Electronic Watt Power Consumption Energy Meter Wattmeter KWh 5-80A 380V AC 50Hz LCD Backlight Display

Description: This table is suitable for the measurement of rated frequency 50 Hz or 60 Hz single-phase ac active electricity, used for fixed installation indoors.
Specifications:
Brand: SINOTIMER
Model:
DDS024Materiel: Metal + ABS
Reference Voltage: 3 X 220/380 (V), 3 X 230/400(VReference
Current: 3 X 5 (80A)
Accuracy Level: 1.0R ated
Frequency: 50HzConstant
Pulse: 400imp
/ kWhDisplay: LCD 6 + 2Power
Consumption: 2W, 10VAStarting
Current: 0.004I bOperating
Temperature: -20 ~ 55CStorage
Temperature: 25 ~ 70COperating
Voltage: 0.9 - 1.1
Rated VoltageUtmost Voltage: 0.8 - 1.15 Rated VoltageAverage Humidity
Value of Year:
75%Type: Three Phase Four Wire Electronic TypeSize:. 10.1 * 7.6 * 6.5 cm / 3.97 * 2.99 * 2.55 in
Features: 1. The meter is fully in conformity with the relevant technical requirements of GB/T 17215.321 -2008 national standard and the IEC62053 international standard of grade 1 or level 2 single-phase energy meter, which can directly and accurately measure active energy of the energy consumption. 2. 6+2 digits LCD display shows the total power consumption. 3. It features high reliability, small volume, light weight, beautiful appearance, advanced technology, and 35mmDIN standard guide rail installation, etc. 4. It has good anti-electromagnetic interference, low power consumption, high precision, high overload, high stability, anti electricity-stolen and long life. 5. Apply to the environment temperature is -25 C ~ 55 C, relative humidity is 95%, and in the air does not contain corrosive gases and avoid dust, mold, salt fog, condensation, insects, etc.
