Adapter PCI-E 5.0 PCI-Express 16x to SFF-TA-1016 Dual MCIO 8i Mini Cool Edge IO VROC Adapter for Mainboard SSD Graphics Card
- One detachable PCIE PCI-Express 8x motherboard can be connected,The converter can be installed into the system internally through the MCIO interface.Only supports motherboards with detachable PCI-E channels.Control the operation of two disks based on the motherboard PCIE channel,The motherboard without PCIE signal split can only recognize one disk.
- Built-in multiple sets of high-power DC modules for sustainable and stable work.High-speed data transfer : The adapter is designed for use with ssd that use MICO 8x connectors, allowing for fast and reliable data transfer at speeds of up to 24 Gbps.
- Easy to use: Simply plug in the MCIO 74 Pin end of the adapter into your device and the MCIO 74pin/38pin end into your external hard drive, and you're ready to go.Mini Cool Edge IO (MCIO) adapter assemblies,These products can provide high performing channels with the added flexibility of where/how to use signals in your system.
- What is mini cool edge Io (MCIO): MCIO adapters are designed for data center, networking and telecommunications markets that use SAS, PCIe, Ethernet and othersignal protocols.The solution can support adapter to board and card to board applications in system, which include chip to chip, chiptomodule, chip to board and card edge option.
- High-performance adapter for networking and server equipment: The MCIO Mini Cool Edge IO is designed to support a wide range of protocols, including SAS, PCIe, Ethernet, and more, ensuring optimal performance for your equipment.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Product Description
Product Description is a high performance, low dielectric loss factor interface conversion card. It connects NVMe SSD or PCIe connectors via MCIO connector . The bandwidth of the card is the bandwidth that the PCIe slot of the motherboard can support. The Motherboard with CPU and BIOS needs to support bifurcation to ensure PCIe x16 link width to bifurcate two x8 link width or four x4 link width for NVMe SSD, Otherwise this card can only support PCIe x16 link width. Features Support up to 4 PCIe devices or NVMe SSDs Compatible with PCIe Gen5, Gen4, Gen3 Directly connected to U.2 NVMe SSD by MCIO to SFF-8639 cable Support bifurcated in quad x4 data link width configuration(CPU and BIOS both support) Support bifurcated in two x8 data link width configuration (CPU and BIOS both support) Build in MCIO 8i connector 2 sets, pin-out defined by SFF-9402 PCIe lane reversal Operating system support The adapter does not require a driver for operation or communication to attached NVMe drives. The drives are presented natively to the host and use the native NVMe drivers. Parameters HARDWARE Model XIC PE5160-4IL Number of Device 4 internal Bus Type PCI Express Interface MCIO 8I CONNECTOR(S) Device Connector 2*MCIO(74 Pin, x8 PCIe Gen 5) Host Bus Type PCI Express x16 Optional Accessories Optional Cables MCIO 8i to 2x SFF-8639 Cable L=0.8m MCIO 8i to MCIO 8i Cable L=0.8m MCIO 8i to 2x MCIO 4i Cable L=0.7m MCIO 8i to SFF-8654 8i Cable L=1m ENVIRONMENTAL Humidity 15% ~ 90% Operating Temperature 5°C to 50°C (41°F to 122°F) Storage Temperature -25°C to 70°C (-13°F to 158°F) PHYSICAL CHARACTERISTICS Dimension 146.5mm x 39.4mm Product Weight 70.5g PACKAGING INFORMATION Shipping (Package)Weight 150 g WHAT'S IN THE BOX Included in Package 1 - PCI Express x16 to Two MCIO 8i NVMe Adapter 1 - Low-profile bracket 1 - Full-height bracket (installed)
