FX600-PT, TFX - Series FIX-CABLE
- FX600-PT, TFX - Series FIX-CABLE
- UPC : 844761023812
- Brand : SilverStone
- Country of Origin : US
- Support standard Flex ATX form factor
- 600W continuous power output at 40 operating temperature rated for 24/7 operation
- Japanese primary capacitor
- Class-leading single +12V rail
- PCIe 8pin and PCIe 6pin connectors support
- Active PFC
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Product No. SST-FX600-PT
Max. DC Output: 600W
Power density: 1212W per liter
Model (safety certification): SST-FX0600FCPT-A
Combined +3.3V & +5V: 80W
Combined +12V: 600W
Input Voltage: 90 ~ 264 Vrms
Input Frequency Range: 47Hz ~ 63Hz
PFC: Active PFC (PF>0.9 at full load)
Efficiency: =89% & <91% overall efficiency
MTBF: 100,000 hours
Operating temperature: 0°C ~ 40°C
Protection:
Over current protection
Over power protection
Over voltage protection
Short circuit protection
Under voltage protection
Over temperature protection
Connectors:
1 x 24 / 20-Pin motherboard connector
1 x 8 / 4-Pin EPS / ATX 12V connector
1 x 8-Pin EPS connector
2 x 8 / 6-Pin PCIe connectors
4 x SATA connectors
3 x 4-Pin Peripheral connectors
1 x 4-Pin Floppy connector
Cooling System:Single 40mm silent fan
Form factor:Flex ATX
Noise Level: 20 dBA minimum
Dimension:
81.5mm (W) x 40.5mm (H) x 150mm (D)
3.21" (W) x 1.59" (H) x 5.91" (D)
Weight: 1.12 kg
Certification: Cybenetics Platinum
