3D Printer Parts GT2 belt 20 teeth GT2 Timing Pulley and 5M GT2-6mm GT2 Timing Belt KIT for 3D printer

Item Type:Belt
Model Number:GT2 belt
Material of belt:Rubber
Material of Pulley:Aluminium
Color:Silver&black
Product name:GT2 belt kit
Teeth Number:20 teeth

GT2 belts and pulleys compliant (GT2 pulley) are popular choices for RepRap tests and traps.
The series GT2 belts are specially designed for the linear movement.
Use a profile with rounded teeth, which ensures that the belt tooth
Perfectly and accurately into the pulley groove, so that if one reverses the direction of the pulley,
there is no place for the band to move
in the groove.
For the best performance, which is at least six teeth in contact with the pulley at a given time.
This minimizes the possibility of sliding ring and h
elps to play in reducing even more.
In practice, this means that you have made at least a pulley 12 teeth.
Feature:
GT2 Timing Belt
GT2 Pitch :2mm
Material: Rubber
Length : 5 meters/volume
Width:6mm
GT2 Timing Pulley(each Piece with 2 Setscrews)
Teeth Number :20teeth
Teeth Pitch:2mm
Material:Aluminium Alloy
Bore of Timing pulley:5&8mm
Color:Silver&Black
Fit to : Timing belt with 6mm Width
