Hot Selling HDMI Video Capture Card USB to HDMI-compatible With Loop Out HD Live Usb External Switch Game PS4 Recording Box

Origin:CN(Origin)
Package:No
Type:Video & TV Tuner Cards
Interface Type:USB

Hot Selling HDMI Video Capture Card USB to HDMI-compatible With Loop Out HD Live Usb External Switch Game PS4 Recording Box
About Description:
Description:
The video capture can capture both HDMI video and HDMI-compatible audio, sending audio and video signals to computers and smart phones for preview and storage. Also can push to online live platfroms to live at the same time, Suitable for HD acquisition, teaching live streaming, game live streaming, Study video capture, Films capture etc.
Features:
1. Support HDMI loop out;
2. Support input max resolution 4K 30fps, the loop out resolution is same as input;
3. Support capture max resolution 1080P 30fps;
4. Support AWG26 HDMI standard cable: input up to 15 meters,
(1080P and below resolution);
5. Support most acquisition software, such as VLCOBS Amcap, etc;
6. Support WindowsLinux and MacOS;
7. Conform to USB Video and UVC standard;
8. Conform to USB Audio UAC standard;
9. Compact and portable.
Specifications:
HDMI resolution: input & loop out Max 4K/30Hz
Support video format: 8/10/12bit Deep color
Video output format: YUVJPEG
Video Capture resolution: Max 1080P/30Hz
Support audio format: L-PCM
Input cable distance: 15m,AWG26 HDMI standard cable
Max working current: 0.7A/5VDC
Operating Temperature range: (-10 to +55)
Dimension (L x W x H): 59x56x19 (mm)
Weight: 52g
Connection and Operation:
1. Connect the UHD signal source to the HDMI input of the video capture with one HDMI cable.
2. Connect the display device to the HDMI output of the video capture with one HDMI cable.
3. Connect PC USB port to the USB output of the video capture with one USB cable.
4. Operation steps for USB video capture(OBS): Open the softwareChoose sources of Video capture DeviceSet the size of imageChoose Studio Mode(double window)Choose Start Recording.
Note:
Computer hardware configuration requirements
CPU: PC i5-3400 or above NB i7-3537U 2.0GHZ or above
Graphics card: PC NVIDIA GT630 or aboveNC NVIDIA GT735M or above
Run memory: 4G RAM.
You'll receive:
1 x Video Capture Card
1 x User Manual
1 x USB Male to Male Cable
1 x Micro USB Cable
