Main image of Delta AFB0612HH 6025 6CM 60mm 0.25A double ball bearing cooling fan for 60*60*25mm

Alt view image 2 of 3 - Delta AFB0612HH 6025 6CM 60mm 0.25A double ball bearing cooling fan for 60*60*25mm

Alt view image 3 of 3 - Delta AFB0612HH 6025 6CM 60mm 0.25A double ball bearing cooling fan for 60*60*25mm

Shop All Graviton Products | Visit Zhongmaozhilian Store

Delta AFB0612HH 6025 6CM 60mm 0.25A double ball bearing cooling fan for 606025mm

Delta AFB0612HH 6025 6CM 60mm 0.25A double ball bearing cooling fan for 60*60*25mm

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Type:IPC Fan
Model Number:AFB0612HH
Origin:Mainland China

Parameters:
Model: AFB0612HH
Size: 60x60x25mm
Rated value: DC12V
Range: DC7.0V-14.0V
Power: 0.25A (nominal current)
Speed: 5000 rpm
Temperature range: -10 ... 70°C
Life expectancy: L10 life expectancy of 40,000 hours at 25°C
Bearing: Maintenance-double ball bearing
Connection: +Red-Black-Blue (and ROO-FOO speed line stall warning, please remember)
Maximum air volume: 17.1 km / m3 / h
Protection: fault protection and locked-rotor lock current protection
Minimum air pressure: 0. 105 Pa
Noise indication: 32.5 dB(a)
Material: FRP, PBT shell, PA blade, environmental certification
Function: Electronically commutated external rotor DC fan, fully commutated electronic parts
