Raspberry Pi Pico SIMCOM SIM868 GSM GPRS GNSS bluetooth module expanding board UART interface

Origin:Mainland China
Model Number:Pico-SIM868

This is a Raspberry Pi Pico expansion board with GSM (Global System for Mobile Communications), GPRS (General Packet Radio Service), GNSS (Global Navigation Satellite System) and Bluetooth (Bluetooth) functions. Me, small size, low power consumption, and powerful! Take me, your Raspberry Pi Pico will be able to easily implement functions such as calling, texting, 2G Internet access, global positioning, and Bluetooth data transmission.
Onboard Raspberry Pi Pico interface, suitable for Raspberry Pi Pico series motherboards
UART interface communication, serial AT command control
Support SMS, phone, GPRS, DTMF, HTTP, FTP, MMS, mail and other functions
Support Bluetooth 3.0, Bluetooth data transmission can be carried out
Support RTC real-time clock, with rechargeable lithium
Onboard 3.7V lithium interface and charging circuit, can be connected to an external rechargeable lithium for external power supply, support charging and discharging
Support microphone and speaker interface, can be used for making calls
Onboard 2 LED indicator lights, easy to check the module running status
Onboard nano SIM card slot, domestic mobile 2G or 4G card*
Provide complete supporting information manuals (sample programs such as Raspberry Pi Pico C/C++ and MicroPython)
Product parameter
1.Pico-SIM868-GSM/GPRS/GNSS × 1
2.LTE antenna × 1
3.GPS antenna × 1
4.Bluetooth antenna × 1
5.20PIN straight seat × 2
6.40PIN straight pin × 1
7.3.7V rechargeable lithium × 1
8.Small speaker × 1
