2000W PSU Antminer Bitmain 2000w Power Supply 6PIN Antminer T9 ETH PSU antminer S9 S7 L3 BTC LTC DASH 1800W miner power supply

Rating Power:> 1000w
Origin:Mainland China
80 PLUS Certification:Other Certification
Model Number:2000W PC Power Supply
Application:Server,Desktop
Modular:Non-Modular
Output:see below
Certification:None
Graphics Card 12V Pin Number:6 pin
Input Voltage:200-264V
Package:Yes
PFC Type:Active

20
00W PSU Antminer Bitmain 2000w Power Supply 6PIN Antminer T9 ETH PSU antminer S9 S7 L3 BTC LTC DASH 2000W miner power supply
Rated Power:  2000w
Interface Type: 6pin x 10 (ONLY 6pin interface)
Working Voltage: AC 180--240V
Rated Power:  2000w
Interface Type: 6pin x 10 (ONLY 6pin interface)
Working Voltage: AC 180--240V
Description:
Features:
100% and !
Model: 1800W PC Power Supply
Connectors: 6 PIN X 10 Pcs
Number of Interfaces:10
Fit For: S9(12.5T/13T/13.5T) S7 L3+D3 APW3 Ant Series Mining Machine
Input Characteristic
Voltage Range: AC 176~264 V
Input Rated Voltage: AC 200~240 V
Starting Inrush Current: 80 A
Maximum Input Current: 10 A
Efficiency: 92%
Output Characteristic
Output Rated Voltage:DC 12.25 V
Load Regulation: ±2%
Linear Regulation: ±1%
Rated Output Power: 1600W(Max)
Output Current: 0~130 A
Output Ripple And Noise: 180 mVp-p
Drive And Shut Down Overshoot Range: ±5%
Rise Time: 100 ms230 V rated load test
Boot Time: 3 S230 V rated voltage test
Hold Up Time: 10 mS230 V rated voltage test
Protection Characteristics
Input Under-voltage Protection Point: 180 V
Input Under-voltage Recovery Point: 185 V
(Can automatic recovery, the backlash is not less than 5V
Input Over-current Protection: Yes
(The over-current point is between 130~160A)
Output Short-circuit Protection: Yes
(Recovery after removal of short circuit)
Input Over Temperature Protection: Yes
(When the temperature switch is higher than 100 degrees, protect, turn off the 12V output, and the temperature can be restored automatically below 65 degrees centigrade.)
Environment Conditions
Operating Temperature: -40~+50 Full Load (Typical value is 25 )
Storage Temperature: -40~+85 (Typical value is 25 )
Operating Humidity: 5~95% Frost-
Storage Humidity: 0~95% Frost-
MTBF: 50000 H (Typical value is 25 )
Altitude: 5000 m (Normal Work)
Heat Dissipation Mode: Air Blast Cooling
