T.F.SKYWINDINTL Power Supply 1600w 120mm Fan 20/24pin 12V ATX PSU For BTC RX470 RX480 RX570 GPU Miner 1600W 12V 133A Miner PSU

Plug Type:EU plug
Number of SATA Ports:8
Application:Desktop,Server
80 PLUS Certification:Other Certification
Approvals:see below
Rating Power:> 1000w
Interface Type:20 + 4Pin
CPU Power Connector:8 pin
Model Number:F1600W
D-type Bus Number:6
Graphics Card 12V Pin Number:2 x6 pin
Input Voltage:184-264V
Package:Yes
PFC Type:Active
Output:see below
Modular:Non-Modular

T.F.SKYWINDINTL
1600W
PC Power Supply Computer PSU 1600W ATX
Asic Bitcoin Miner Ethereum rx 480 rx 470 rx 570 Mining Power Supply
Rated Power: 1600 W
Size(L*W*H): 160 x 150 x 85 mm
(Please allow 0-2cm error due to manual measurement)
Power Supply Grade: 90 PLUS GOLD
Input Voltage: AC 140~264 V
Input Current: 8 AAt 220 V AC
Input Frequency: 47 Hz~63 Hz
Conversion Efficiency: 90%
Input Efficiency:88%50%Load AC 220 V/50 Hz
Earth Resistance Value:0.1 ohms (32 A)
Power Factor:0.96(Full Load AC 220V)
Over-voltage Protection: Yes
Short-circuit Protection: Yes
Over Power Protection: Yes
Environment Conditions
Operating Temperature: 0~55
Storage Temperature: -40~70
Operating Humidity: 5%~85%
Storage Humidity: 5%~95%
Cooling Method: Air Cooling 14 cm Fan
Interface:
1PCS *CPU 4+4PIN
1 PCS *Main Board 24PIN
12 Pcs *Video Cards 6+2P
6 Pcs* IDE
8 Pcs* SATA
Support Graphics Card Type & Quantity:
Graphics Card 1060,6 Pieces
Graphics Card 370,6 Pieces
Graphics Card 380,6 Pieces
Graphics Card 380X,6 Pieces
Graphics Card 470,6 Pieces
Graphics Card 480,6 Pieces
Graphics Card 570,6 Pieces
Features:
1.Support 6 pieces graphics card.
2.1600W power supply, high efficiency,very quiet,stable performance.
3:Universal AC input
4:Short circuit protection,over voltage protection ,over current protection
5:air convection
6:Low cost ,high reliability
