Charging Control Module XH-M603 Digital LED Display Storage Lithium Charger Control Switch Protection Board

Origin:CN(Origin)

Condition:

Type:Voltage Regulator

Application:Computer

Supply Voltage:1

Dissipation Power:1

is_customized:Yes

XH-M603 Charging Control Module 12-24V Storage Lithium Charger Control Switch Protection Board

Product Introduction:

1.Model:XH-M603

2.Input Voltage:DC 10-30V

3.Display Precision:0.1V

4.Control Precision:0.1V

5.Output Type:direct output

6.Voltage Tolerance:+/-0.1V

7.Application Fields:12-24V storage

8.Size;82*58*18mm

Using Method:

1.Set Starting Voltage:in normal display voltage state,press the button will display start charging voltage;long press for 3s the digital tube will flash;you can start or stop button to set starting up charge voltage value

2.Set Stop Voltage:in normal display voltage state,press the button will display stoping charge voltage;long press the button for 3s the digital tube will flash;you can start or stop button to set stoping charge voltage value

3.Factory Reset:in power on state press the start/stop button at the same time,digital tube will display 888;that represents factory reset settings
