Description
This Dual Band Adapter delivers powerful wireless technology to your desktop or notebook computer. Simply plug the adapter into an available USB port and connect to a wireless network to access a secure, high-speed internet connection 2.4GH z (150Mbps) or 5GHz (up to 433Mbps). And with integrated Dual Band technology
Features
Chipset: 8811
System: for Win10/ 8.1 /8/7/xp/vista; 32/64bits; for MAC OS; for Linux
Supports 802.11 ac standard- The next generation of Wi-Fi
Backward compatible with 802.11 a/b/g/n products
Ultra-fast AC600 (433+150Mbps) wireless speed with 802.11 ac
Maximum speed up to 5GHz 433Mbps or 2.4GH z 150Mbps
Dual Band connections for large-free HD video streaming and gaming
Specification
Wireless Standards: IEEE 802.11 ac IEEE 802.11 n IEEE 802.11 g IEEE 802.11 b
Transmit Speed
802.11 b: 1/2/ 5.5 /11Mbps
802.11 g: 6/9/12/18/24/36/48/54Mbps
802.11 n: up to 150Mbps
802.11 ac: up to 433Mbps
Frequency Range:
2.412 ~ 2.4835 GHz
5.180 ~ 5.320GH z
5.500 ~ 5.700GH z
5.745 ~ 5.825GH z
Work Channel:
1 ~ 13( 2.4G )
36 ~ 165 (5G)
Work Power: 18dBm (Typical)
Sensitivity:
11n: -68dBm@130M; -68dBm@108M
11g: -69dBm@54M
11b: -85dBm@11M
11ac: -59dBm@433M
Wireless Security: WPA/WPA2/WPA-WPA2/ 802.1 x
64/128 bit WEP
Support Operation System:
for Win xp, vista, win7, win8, win10;
for mac 10.5 ~mac 10.8;
for Linux Driver for Kernel 2.6. 18~ 2.6. 38 and 3.0. 2;
for Android 1.6 ~ 2.3 and 4.0
Chipset: Realtek8811
Host Interface: USB 2.0
LED (BLUE): Link/Act
Antenna Type: 2dbi SMA
Size: 45x20x10mm (with out antenna)
Environment:
Operating Temperature: 0~45
Storage Temperature: -20~75
Operating Humidity: 10% ~ 90% RH (Non Condensing)
Storage Humidity: 5% ~ 95% RH (Non Condensing)
Package Included
1* Wireless USB Adapter
1* 2 dBi Antenna
