Stepper Drive Control Board Speeds Regulation PWM Controller Module Board Positive Negative Rotation Control 12-24V for MKS OSC

PWM Signal Generating Controller Speeds Regulation Stepper Motor Pulse Signal Generating Module Positive Negative Rotation Control 12-24V Electronic Components
Features:
1.
User-Friendly: This stepper motor driver controller module offers a simple and easy-to-use solution for controlling the speed, direction, and PWM signal generation of your stepper motor system.
2. Safe and
Reliable: With a wide input voltage range of 8-24V and built-in safety features, this stepping motor controller module ensures safe and reliable operation for your stepper motor control needs.
3.
Comprehensive Functionality: Featuring
adjustable frequency signals (high: 5.4 k-160kHz, medium: 540- 16.6 kHz, low: 80- 2.4 kHz) and the ability to generate both pulse and PWM signals, this PWM signal generating controller module provides comprehensive functionality to meet different control requirements.
4.
Direction Control: This stepper motor pulse signal generating module allows for easy switching between clockwise and counterclockwise rotation, giving you full control over the direction of your stepper motor.
5.
Compact Size: With dimensions of 58.00 x 51.00 x 13.00 mm ( 2.28 x 2.01 x 0.51 inches), this stepper drive control module is compact and space-saving, making it suitable for various applications where size constraints may be a concern.
Specification:
Origin: Mainland China
Type: Module
Condition: New
Model Number: Stepper Motor Controller Board
Input Voltage: 8~24V
Frequency Paradigm: High 5.4 k-160khz, Medium 540- 16.6 khz, Low 80- 2.4 khz
Signal Type: Pwm/Pulse
Direction: Clockwise/Counterclockwise
Size: 58.00 x 51.00 x 13.00 mm/ 2.28 x 2.01 x 0.51 inch
Product Description:
This module is a pulse generator module, supplying the stepper driver as a signal.
If you want to control the stepper motor, you must also be equipped with a driver to do so.
This simple controller + stepper driver + stepper motor + DC power supply can form a set of simple control platform.
Controller has a high 5.4 k-160khz, 540- 16.6 khz, low 80- 2.4 khz a total of three kinds of frequency signals can be selected with a jumper.
It can generate pulse signals or PM signals, which can be selected by jumper wires.
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
1*Stepper Motor Controller Board
