42/57/86 Stepper Motor driver 32 Subdivision 4.0A40VDC driver module TB6600 upgrade
Limited time offer, ends 07/29 By E-tech
- This drive is an upgraded version of the TB6600, with the subdivision increased to 32 subdivisions for high subdivision use.
- Stepper motor: 42, 57, 86 type 2 phase 4 phase (4 lines 6 lines 8 lines) Product parameters: 1, 9V-40V DC power supply;
- 2, H bridge bipolar constant phase flow drive;
- 3, maximum 4.OA's eight output currents are optional;
- 4, the maximum 32 subdivisions of 6 subdivisions can be selected;
- 5, input signal high-speed photoelectric isolation;
- 6, standard common positive single pulse interface;
- 7, offline hold function;
- 8, semi-closed shell can adapt to more stringent environment;
- 9, provide energy-saving semi-automatic current locking function;
- 10, built-in temperature protection and overcurrent protection.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
This drive is an upgraded version of the TB6600, with the subdivision increased to 32 subdivisions for high subdivision use.
Stepper motor: 42, 57, 86 type 2 phase 4 phase (4 lines 6 lines 8 lines)
Product parameters: 1, 9V-40V DC power supply;
2, H bridge bipolar constant phase flow drive;
3, maximum 4. OA's eight output currents are optional;
4, the maximum 32 subdivisions of 6 subdivisions can be selected;
5, input signal high-speed photoelectric isolation;
6, standard common positive single pulse interface;
7, offline hold function;
8, semi-closed shell can adapt to more stringent environment;
9, provide energy-saving semi-automatic current locking function;
10, built-in temperature protection and overcurrent protection.
Stepper motor: 42, 57, 86 type 2 phase 4 phase (4 lines 6 lines 8 lines)
Product parameters: 1, 9V-40V DC power supply;
2, H bridge bipolar constant phase flow drive;
3, maximum 4. OA's eight output currents are optional;
4, the maximum 32 subdivisions of 6 subdivisions can be selected;
5, input signal high-speed photoelectric isolation;
6, standard common positive single pulse interface;
7, offline hold function;
8, semi-closed shell can adapt to more stringent environment;
9, provide energy-saving semi-automatic current locking function;
10, built-in temperature protection and overcurrent protection.
