ezcap327 4K HDMI SDI high-definition video capture live streaming box
- Function Introduction
- -1080p60 3G-SDI input.
- -2160p30 HDMI input.
- - HDMI output - SDI input supports up to 1080P60, HDMI input supports up to 2160P30.
- The maximum support for live streaming is 2160p30, 1440p60, and 1080p120.
- Video output formats: NV12, YUY2, XRGB and P010.
- - UVC technology, no need to install drivers manually.
- - Supports the vast majority of third-party video capture and live streaming software.
- It comes with a powerful self-developed video capture and live streaming software: ezcap LinK, which can capture, live stream and serve as a virtual camera
- Ultra-high-speed USB 3.1
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Specification parameters
- Host interface: USB 3.1
Video input: SDI, HDMI
- Audio input: SDI, HDMI
- Video output: HDMI
- Audio output: HDMI
- Application connection devices: cameras, medical equipment, etc
- HDMI output maximum resolution: SDI
input: 1080p60.
HDMI input: 1080p120, 2160p30
- Maximum output video format of the device: NV 12: 2160 p30/1080p120- Only valid for HDMI input, 1440p60, 720p60. YUY 2: 1080 p60, 1440p50, 720p60.
XRGB: 1080p30, 720p60.
- Maximum acquisition resolution:
SDI: 1080p60.
HDMI: 2160p30, 1080p120, 1440p60.
- Working indicator lights: SDI input, HDMI input, power supply, working.
- Supported software: OBS Studio (Windows, OS X), OBS Broadcast (Windows, Mac OS X), Adobe Flash Media Live Encoder (Windows, OS X), Real Producer Plus (Windows), QuickTime Broadcaster (OS X), QuickTime Player (OS X), Windows Media Encoder (Windows), Potplayer (Windows), Xsplit Broadcaster (Windows, OS X), VLC (Windows, OS X, Linux), Wirecast (Windows, OS X), vMix (Windows), AMCAP, and etc.
- System Requirements:
Windows 10 x 64
Laptop: 4Kp30 or 1080p120
Recording: Intel Core i7-7700HQ, NVIDIA GeForce GTX1050 Ti, 8GB
RAM. 1080p60 recording: Intel Core i7-4810MQ, NVIDIA GeForce GTX 870M, 8GB RAM.
Desktop computer: 4Kp30 or 1080p120
Recording: Intel Core i5-6XXX/AMD, Ryzen 3 XXX or above, NVIDIA GTX 1060 / AMD RX 5700, 8GB
RAM. 1080p60 recording: Intel Core i7-3770 recommended, NVIDIA GeForce GTX 650 / AMD Radeon R7 250X, 4GB RAM.
Mac OS High Sierra 10.15 or above
iMac 2019: 3. 2GHz 6-core Intel Core i7, Radeon Pro 555X 2GB GDDR5, 16GB 2400MHz DDR4. MacBook Pro 2018: 2. 6GHz 6-core Intel Core i7, Radeon Pro 560X 4GB of GDDR5, 16GB 2400MHz DDR4.
- Packaging contents: ezcap327 USB Cam Live SDI acquisition live broadcast, USB Type-C to A data cable, USB Type-C to C data cable, instruction manual
- Dimensions: 105 x 66 x 27 mm
- Host interface: USB 3.1
Video input: SDI, HDMI
- Audio input: SDI, HDMI
- Video output: HDMI
- Audio output: HDMI
- Application connection devices: cameras, medical equipment, etc
- HDMI output maximum resolution: SDI
input: 1080p60.
HDMI input: 1080p120, 2160p30
- Maximum output video format of the device: NV 12: 2160 p30/1080p120- Only valid for HDMI input, 1440p60, 720p60. YUY 2: 1080 p60, 1440p50, 720p60.
XRGB: 1080p30, 720p60.
- Maximum acquisition resolution:
SDI: 1080p60.
HDMI: 2160p30, 1080p120, 1440p60.
- Working indicator lights: SDI input, HDMI input, power supply, working.
- Supported software: OBS Studio (Windows, OS X), OBS Broadcast (Windows, Mac OS X), Adobe Flash Media Live Encoder (Windows, OS X), Real Producer Plus (Windows), QuickTime Broadcaster (OS X), QuickTime Player (OS X), Windows Media Encoder (Windows), Potplayer (Windows), Xsplit Broadcaster (Windows, OS X), VLC (Windows, OS X, Linux), Wirecast (Windows, OS X), vMix (Windows), AMCAP, and etc.
- System Requirements:
Windows 10 x 64
Laptop: 4Kp30 or 1080p120
Recording: Intel Core i7-7700HQ, NVIDIA GeForce GTX1050 Ti, 8GB
RAM. 1080p60 recording: Intel Core i7-4810MQ, NVIDIA GeForce GTX 870M, 8GB RAM.
Desktop computer: 4Kp30 or 1080p120
Recording: Intel Core i5-6XXX/AMD, Ryzen 3 XXX or above, NVIDIA GTX 1060 / AMD RX 5700, 8GB
RAM. 1080p60 recording: Intel Core i7-3770 recommended, NVIDIA GeForce GTX 650 / AMD Radeon R7 250X, 4GB RAM.
Mac OS High Sierra 10.15 or above
iMac 2019: 3. 2GHz 6-core Intel Core i7, Radeon Pro 555X 2GB GDDR5, 16GB 2400MHz DDR4. MacBook Pro 2018: 2. 6GHz 6-core Intel Core i7, Radeon Pro 560X 4GB of GDDR5, 16GB 2400MHz DDR4.
- Packaging contents: ezcap327 USB Cam Live SDI acquisition live broadcast, USB Type-C to A data cable, USB Type-C to C data cable, instruction manual
- Dimensions: 105 x 66 x 27 mm
