105W tube amplifier power transformer+5K: 4O 8O single-ended output transformer*2, suitable for 6P1 6P14 6P6P

Coil Number: Autotransformer

is_customized: Yes

Phase: Single

Usage: AUDIO

105W power transformer

Iron core EI 86*50 0.5 mm silicon steel sheet

The wire package is made of high temperature resistant oxygen-copper wire

Skeleton 28*50 iron core stack thickness 50mm

Horizontal style with top cover

Primary input voltage; 0-220V-230V

Output voltage; high voltage 230V-0-230V 150mA

Filament 3.15V -0- 3.15V 3A

0- 6.3V 2A

0-5V 3A

Transformer size, length 90mm width 74mm height 91mm

Square hole opening size; 55*48mm

Four-hole screw hole distance, 58mm*70mm

Weight; 2.45KG /piece

EI57 core

5K series amplifier transformer, 6P 1.6P 14.6P 6 single-ended output transformer

Frame 19X26 (tongue width 19. stack thickness 26)

Beginner 5 K

Winding method; 3+2 fever grade winding

Secondary 04O8O

Length; 60mm

Width; 55mm

Height; 50mm

Center distance of mounting hole; 73mm

Shielding method; black painted iron shell fully shielded

All of our product raw materials are made of EI series annealed silicon steel sheet, enameled wire drawn by high temperature resistant oxygen-copper rod

Weight; 0.56 kg each
