Openwrt Router 1200 Mbps Wireless Router 5Ghz Smart App Manage Wifi Router Large Coverage 802.11ac Support DDNS/WPS

Specification

Main Chipset

MT7628A+MT7612E

RAM

DDR2 64MB

SPI FLASH

8MB

Protocol

IEEE802.11ac, 802.11a, 802.11n, 802.11g, 802.11b, 802.3, 802.3u

RT Power

11n: 17dBm±1dBm 11g: 17dBm±1dBm 11b: 19dBm±1dBm 11a: 16dBm±1dBm 11ac: 14dBm±1dBm

Reception Sensitivity

11n: -82dBm 11g: -82dBm 11b: -76dBm 11a: -82dBm 11ac: -76dBm

Work Channel

2.4GHz choose1-13 5GHz choose149153157161165

Wireless Rate

Max 1166Mbps

Work Frequency

2.4GHz,5.0-5.8GHz

Antenna

For 2.4GHz,2*undetachable 5dBi antenna, for dual band,2*undetachable 5dBi antenna,

Interface

1*USB 2.0 interface 1*Micro TF card slot 1*10/100M WAN PortAuto MDI/MDIX 4*10/100M LAN PortsupportAuto MDI/MDIX

LED

Power,USB,2.4G,5G,WAN,LAN1,LAN2,LAN3,LAN4

Button

Reset

Max Power Consumption

12W

WAN Type

PPPoEDynamicIPStatic IP

Work Mode

AP; Router;

DHCP

Server, Client, DHCP Client List, Address Reservation

Port Forwarding

Virtual Server, Port Triggering, UPnP, DMZ

Firewall Security

Dos, SPI Firewall IP Address Filter/MAC Address Filter/ Domain Filter IP and MAC Address Binding

DDNS

Support

VPN Pass-Through

PPTP, L2TP, IPSec (ESP Head)

Static Router

Support

Other Function

Mac clone NTP Synchronize Web software update

Work Environments

Adapter

12V 1A
