ADF4351/ADF4350 Development Board - Wideband PLL RF Signal Source Generator Module (35MHz-4400MHz) with SMA Connector for Radio Enthusiasts and Electronics Testing
- I. Product Introduction
- The core chip adopts the ADF4351, following the official principle and optimizing the layout. The entire module exhibits extremely high power flatness within the working frequency band.
- II. Product Specifications
- Output frequency range: ADF4351: 35 MHz - 4400 MHz (4.4 GHz)
- 4. Output signal: 2200M - 4400M fundamental wave (sine wave) 35M - 2200M fundamental wave frequency division (square wave)
- 5. Output signal interface: SMA female connector
- 6. The default tolerance is ±50ppm for 25M imported active crystal oscillator. Circuit diagrams in PDF format and STM32 test programs are provided.
- 7. Control method: Three-wire SPI. The control pins and lock status pins are provided. All functions can be realized, including point frequency, sweep frequency and jump frequency. The step size can reach 1K, and the low-frequency step size can reach 0.1K, which is determined by the crystal frequency.
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
I. Product Introduction
The core chip adopts the ADF4351, following the official principle and optimizing the layout. The entire module exhibits extremely high power flatness within the working frequency band.
II. Product Specifications
Output frequency range: ADF4351: 35 MHz - 4400 MHz (4.4 GHz)
4. Output signal: 2200M - 4400M fundamental wave (sine wave) 35M - 2200M fundamental wave frequency division (square wave)
5. Output signal interface: SMA female connector
6. The default tolerance is ±50ppm for 25M imported active crystal oscillator. Circuit diagrams in PDF format and STM32 test programs are provided.
7. Control method: Three-wire SPI. The control pins and lock status pins are provided. All functions can be realized, including point frequency, sweep frequency and jump frequency. The step size can reach 1K, and the low-frequency step size can reach 0.1K. It is determined according to the crystal frequency.
III. Important Notes
It can be powered by 3.3v pins, and the power supply can provide a current of no less than 500mA.
2. The typical power supply voltage is 5 volts.
IV. Shipping List
1. One 35M - 4400M radio frequency signal generation module
