5Pcs AMS1117 Multi-Channel DC-DC Voltage Conversion Module 12V to 3.3V 5V 12V
- Multi-Channel DC Power Conversion Module: This power module provides multiple DC output rails from a single DC input, including 3.3V, 5V, and 12V outputs. It is ideal for Arduino projects, breadboard experiments, sensor testing, microcontroller development, and DIY electronics prototyping.; DC 6V12V Input Range: The module supports a DC 6V12V input range and offers 3.3V and 5V regulated outputs, plus a 12V pass-through output when using a 12V input. The input voltage should be at least 1V higher than the required regulated output voltage.; AMS1117 Regulated Outputs: Built with AMS1117 linear regulators, the module provides stable 3.3V and 5.0V outputs with approximately ±0.05V tolerance. It is suitable for powering development boards, logic circuits, sensors, communication modules, and other low-power electronic components.; Breadboard-Friendly Pin Header Design: Designed with two pin header mounting holes, this module can be directly mounted on a breadboard for convenient expansion experiments. Multiple input and output pin headers make wiring simple and help reduce messy jumper connections during prototyping.; Compact PCB with Power Indicator: The 45 × 45mm double-sided PCB features a clean layout and an onboard power indicator LED for easy status checking. The maximum load current should be kept below 800mA, and adequate heat dissipation is recommended when operating with higher current or larger voltage drops.
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Multi-Channel DC-DC Voltage Conversion Module, 12V to 3.3V / 5V / 12V AMS1117 Power Supply Module
Product
Input Voltage: DC 6V12V
Output Voltages: 3.3V, 5.0V, DC-IN/OUT pass-through 3.3V
Output Accuracy: 3.3V ± 0.05V 5V
Output Accuracy: 5.0V ± 0.05V 12V
Output: 12V input can be directly converted to DC-IN/OUT output
Output Current: Less than 800mA
PCB Size: Approx. 45mm × 45mm
Power Indicator: Onboard LED indicator
PCB Design: Double-sided PCB
Connection Method: DC input connector and pin header output ports
Pin Definitions DC-IN: DC input connector 5V
OUT: Regulated 5V output terminal 3.3V
OUT: Regulated 3.3V output terminal
DC-IN/OUT: Input voltage pass-through output terminal
GND: Output negative terminal Usage Notes The input voltage range is DC 6V12V. Do not exceed the rated input voltage For stable operation, the input voltage should be at least 1V higher than the desired regulated output voltage. The load current should be kept below 800mA. Check the polarity before powering the module. Incorrect wiring may damage the board or connected devices.
Product
Specifications
Product Name: Multi-Channel DC-DC Voltage Conversion Module Regulator Type: AMS1117 linear voltage regulatorInput Voltage: DC 6V12V
Output Voltages: 3.3V, 5.0V, DC-IN/OUT pass-through 3.3V
Output Accuracy: 3.3V ± 0.05V 5V
Output Accuracy: 5.0V ± 0.05V 12V
Output: 12V input can be directly converted to DC-IN/OUT output
Output Current: Less than 800mA
PCB Size: Approx. 45mm × 45mm
Power Indicator: Onboard LED indicator
PCB Design: Double-sided PCB
Connection Method: DC input connector and pin header output ports
Pin Definitions DC-IN: DC input connector 5V
OUT: Regulated 5V output terminal 3.3V
OUT: Regulated 3.3V output terminal
DC-IN/OUT: Input voltage pass-through output terminal
GND: Output negative terminal Usage Notes The input voltage range is DC 6V12V. Do not exceed the rated input voltage For stable operation, the input voltage should be at least 1V higher than the desired regulated output voltage. The load current should be kept below 800mA. Check the polarity before powering the module. Incorrect wiring may damage the board or connected devices.
