LC Coaxial Filter Frequency 1MHz Passive Low-Pass High-Pass Filter with SMA BNC Connectors (HPF SMA Dual Female)

Be the first to review this product...

Pure copper housing with nickel-plated surface, port impedance 50 ohms.; Maximum input power: 100m W (Maximum input signal strength: 20dBm).; Operating frequency range: DC-1000MHz, Operating ambient temperature: -40°C to 80°C.; LPF BNC Filter 1MHz Insertion Loss (IN-OUT) in Passband: DC-1MHz / <1.0dB.; LPF BNC Filter 1MHzStopband (Out-of-Band Rejection): 3.5MHz-1000MHz / >60dB. In-band ripple: DC-1MHz /

Overview

Specs

Reviews

Any questions? Our AI mode will help you find out quickly.

Try me now

JMT LC Coaxial Filter Frequency 1MHz Passive Low-Pass High-Pass Filter with SMA BNC Connectors LPF BNC
Filter 1MHz Description: Pure copper housing with nickel-plated surface, port impedance 50 ohms. BNC connectors on both ends.
Dimensions: LPF BNC Male+Female Length*Diameter (52mm* 14.5 mm).
Finished weight: 30g
Maximum input power: 100m
W (Maximum input signal strength: 20dBm).
Operating frequency range: DC-1000MHz, Operating
ambient temperature: -40°C to 80°C.

Specifications

:
Project: Frequency Range / Typical Value Insertion Loss (IN-OUT) in
Passband: DC-1MHz / <1.0dB Stopband (Out-of-Band Rejection): 3.5MHz-1000MHz / > 60dB
VSWR: DC-1MHz / >17dB (< 1.3 )
In-band ripple: DC-1MHz / ± 0.25 dB
Phase Shift: Phase Coherence / ±3°
Group Delay Ripple: DC-1MHz / <700ns
Input Voltage Withstand: In&Out
/ max: DC50V

Model
Brand	Fenvit
