Honeywell Hyperion 1300g Wired Light Industrial Linear-imaging 1D Barcode Scanner, RS232/USB/KBW/IBM, Ivory, USB Kit - 1300G-1USB
- Aggressive Handheld Scanning increases throughput with intuitive and aggressive scanning of standard 1D and GS1 DataBar symbols
- Reads out to 45.7 cm (18 in) on 13 mil barcodes and reads high density barcodes as small as 3 mil
- Increases up time and reduces service costs thanks to a reliable design that has no moving parts and features full impact resistant bumpers
- Ensures operator comfort and productivity with a gun-shaped form factor optimized for intensive handheld scanning
- Supports all popular interfaces in one device, replacing the time-consuming process of scanning programming barcodes
- With no moving parts to wear out, the Hyperion 1300g is one of the toughest general duty scanners on the market
- USB Kit includes: 1D, ivory scanner (1300g-1), USB Type A 3m straight cable (CBL-500-300-S00)
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Honeywell 1300g
General
Brand
Honeywell
Series
Hyperion
Model
1300g
Part Number
1300G-1USB
Form Factor
Handheld
Connectivity
Corded
Scan Engine
1D Linear Imager
Connectivity
Included Cables
USB Cable Included
Interfaces Supported
Multi-Interface / includes RS232 (TTL +5V, 4 Signals) / KBW / USB (HID keyboard, serial, IBM OEM);
RS-232C (+/-12V) and IBM RS485 supported via adapter cable
Scan Performance
Light Source
Light Levels: 0 - 70,000 lux (direct sunlight)
Pitch
±65 degree
Yaw
±65 degree
Scan Speed
Up to 270 scans per second
Print Contrast Ratio (Minimum)
20% minimum reflectance difference
Decoding Capability
Reads standard 1D and GS1 DataBar symbologies
Electrical
Input Voltage
5V +/- 5%
Power Consumption
Operating Power: 1000 mW; 200 mA (typical) @ 5V
Standby Power: 625 mw; 125 mA (typical) @ 5V
Mechanical
Color
Ivory
Dimensions
5.90" x 4.40" x 3.10"
Weight
0.35 lb.
Features
Features
Superior Hand-Held Scanning:
Increases throughput by offering intuitive and aggressive hand-held scanning performance
Highly Versatile:
Eliminates the need to purchase specialty scanners by providing the ability to read out to 18 inches (457.00 mm) on 13.00 mil bar codes, as well as high density bar code reading in a single device
Class-Leading Durability:
Increases up time and reduces service costs with a reliable design that utilizes no moving parts and full impact resistant bumpers
Comfortable, Ergonomic Design:
Ensures operator comfort and productivity with a gun-shaped form factor optimized for intensive hand-held scanning
Automatic Interface Detection:
Supports all popular interfaces in one device, replacing the time consuming process of scanning programming bar codes with automatic interface detection and configuration
Remote MasterMind Scanner Management Software:
Provides a quick and convenient solution for IT administrators seeking to manage all scanners within their network from a single remote location
Drop
Designed to withstand 50 drops on concrete from 1.50 m
General
Brand
Honeywell
Series
Hyperion
Model
1300g
Part Number
1300G-1USB
Form Factor
Handheld
Connectivity
Corded
Scan Engine
1D Linear Imager
Connectivity
Included Cables
USB Cable Included
Interfaces Supported
Multi-Interface / includes RS232 (TTL +5V, 4 Signals) / KBW / USB (HID keyboard, serial, IBM OEM);
RS-232C (+/-12V) and IBM RS485 supported via adapter cable
Scan Performance
Light Source
Light Levels: 0 - 70,000 lux (direct sunlight)
Pitch
±65 degree
Yaw
±65 degree
Scan Speed
Up to 270 scans per second
Print Contrast Ratio (Minimum)
20% minimum reflectance difference
Decoding Capability
Reads standard 1D and GS1 DataBar symbologies
Electrical
Input Voltage
5V +/- 5%
Power Consumption
Operating Power: 1000 mW; 200 mA (typical) @ 5V
Standby Power: 625 mw; 125 mA (typical) @ 5V
Mechanical
Color
Ivory
Dimensions
5.90" x 4.40" x 3.10"
Weight
0.35 lb.
Features
Features
Superior Hand-Held Scanning:
Increases throughput by offering intuitive and aggressive hand-held scanning performance
Highly Versatile:
Eliminates the need to purchase specialty scanners by providing the ability to read out to 18 inches (457.00 mm) on 13.00 mil bar codes, as well as high density bar code reading in a single device
Class-Leading Durability:
Increases up time and reduces service costs with a reliable design that utilizes no moving parts and full impact resistant bumpers
Comfortable, Ergonomic Design:
Ensures operator comfort and productivity with a gun-shaped form factor optimized for intensive hand-held scanning
Automatic Interface Detection:
Supports all popular interfaces in one device, replacing the time consuming process of scanning programming bar codes with automatic interface detection and configuration
Remote MasterMind Scanner Management Software:
Provides a quick and convenient solution for IT administrators seeking to manage all scanners within their network from a single remote location
Drop
Designed to withstand 50 drops on concrete from 1.50 m
