PCIe x4 to 2 PORTS SATA 3.0 + B key NGFF(m.2) RAID Card HyperDuo SATA port multiplier 88SE9230 SATA3.0 WIN10 Expanding heat sink

Type:Add On Cards
Model Number:PCIe to NGFF +SATAIII RAID Card
Package:No
Interface Type:PCI Express
is_customized:Yes

Features
This Dual SATA III + Dual NGFF(m.2) Port PCI-E X4 Card, HyperDuo adds 2 AHCI SATA III ports and 2 NGFF(m.2) ports to a computer through a PCIe x4 slot(actual x2 speed)
Expanding heat sink
, it supports Port Multiplier (PM), enabling multiple SATA drives to be connected to one port over a single cable. Plus, the SATA controller card offers an effective RAID solution, with native RAID (0, 1, 1+0) support.
Chipset: Marvell 88SE9230
Compliant with PCI-Express Specification V2.0 and Backward Compatible with PCI-Express 1.x
Compliant with Serial ATA Specification 3.0
PCI-Express x4 Interface(actual x2 speed) is Compatible with PCI-Express x4, x8, and x16 slots
Supports Communication Speeds of 6.0 Gbps, 3.0 Gbps, and 1.5 Gbps
Hot Plug and Hot Swap
Supports Native Command Queue (NCQ)
Supports Port Multiplier FIS Based Switching or Command Based Switching
Only supports B key M.2 NGFF PCIe based SSD
Movable M.2 NGFF stand-off and multiple plated-holes supports type 22110, 2280, 2260, 2242 and 2230 SSD
Support RAID function: RAID 0, RAID 1,RAID1+0
HyperDuo technology
Support Os:WindowsXP/Vista/7/8/10/Server 2008 R2 / 8,Linux 2.6.x and above
Package
Sata3.0PCIe Adapter  X1
Driver CD  X 1
General manual X 1
Performance testing:
