MEAN WELL 60W24V Rail Type Switching Power Supply 2.5A Voltage Regulator Industrial Control PLC Sensor

· Model Name: MDR-60-24
· Output Wattage: 60 Watts
· Brand: MEAN WELL
· Item Dimensions LxWxH: 1.57 x 3.54 x 3.94 inches
· Item Weight: 10.4 ounces

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

"60W DIN-Rail switching Power Supply
24 Volts 2.5 Amps Specifications
Universal AC input range
Protections: Short-circuit, Overload, Overvoltage
100% Full load burn-in test
Soft-start circuit, limiting AC surge current
Input Voltage: 85-264VAC 47-63Hz, or 120-370VDC
Input Current Full load: 1.8A(115V) / 1.0A(230V)
Size: 3.9 x 1.6"" x 3.5""
Weight: 0.7 lbs.
3-year warranty
Detailed Specifications:
Primary Output Voltage (VDC): 24
Output Current (A): 2.5
Maximum Output Power (W): 60
Family: MDR-60
Input Voltage (VAC): 85 to 264
Input Frequency: 47 to 63
Maximum Input Current (A): 1.8
Output Connector Type: Screw Terminal
Efficiency (%): 88
Operating Temperature-Min (Cell): -20
Operating Temperature-Max (Cell): 70
Length (inch): 1.57
Width (inch): 3.54
Height (inch): 3.94
Agency Approvals: UL/CUL/TUV/CB/CE
Color: White
Style: DIN.
