SDR-480-48 AC to DC DIN-Rail Power Supply 48V 10 Amp 480W

480W Single Output Industrial DIN RAIL with PFC Function 48 Volts 10 Amps Features: Current sharing up to 3840W(7+1) High efficiency 94% and low power dissipation 150% peak load capability Built-in active PFC function, PF>0.94 Protections: Short circuit / Overload / Over voltage / Over temperature Cooling by free air convection Built-in constant current limiting circuit Can be installed on DIN rail TS-35/7.5 or 15 248736 UL 508(industrial control equipment)approved EN61000-6-2(EN50082-2) industrial immunity level 100% full load burn-in test 3 years warranty Built-in DC OK relay contact 150% peak load capability Detailed Specifications: Primary Output Voltage (VDC): 48 Output Current (A): 10 Maximum Output Power (W): 480 Family: SDR-480 Input Voltage (VAC): 90 to 264 Input Frequency: 47 to 63 Maximum Input Current (A): 5 Output Connector Type: Screw Terminal Efficiency (%): 94 Operating Temperature-Min (Cell): -25 Operating Temperature-Max (Cell): 70 Length (inch): 3.37 Width (inch): 4.93 Height (inch): 5.06 Agency Approvals: UL/CUL/TUV/CB/CE Color: Silver Style: DIN.
