Kulon Mean Well Original LRS-100-24 24V 4.5A meanwell LRS-100 24V 108W Single Output Switching Power Supply
- The height is only 30mm, the performance of the high-end model, the price of the economy, high efficiencylong life and reliability ,the quality assurance for three years.
- Protection Short cirsuit/ Overload/ Over voltage ;cooling by free air convection;High operating temperature up to 70.
- 100% original,We can check the serial number on the meanwell website.
- Compliance to IEC/EN60335-1(PD3) and IEC/EN61558-1.-2-16 for household applicaces
- The application fields include industrial automation equipment, industrial control system, mechanical and electrical equipment, electronic instrument and equipment, appliance application and so on.
+
+
Overview
Reviews
Product Details: Brand Name:Meanwell
Model Number:LRS-100-24
Output Power:108W
Output Type:Single
Input Voltage:85 ~ 264VAC
Output Voltage:24V
Output Frequency:47 ~ 63Hz
Output Current:0~4.5A
Dimension:129*97*30mm (L*W*H)
Certification:TUV / CCC / CB / CE
Warranty:3 Years
Efficiency:90%
Feature:Low profile, low cost
Application:Various industrial applications
Protections:Short Circuit Overload Overvolt
Type:Single output
Features: Universal AC input / Full range
Withstand 300VAC surge input for 5 second
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Miniature size and 1U low profile
Compliance to IEC/EN 60335-1 (PD3) and IEC/EN61558-1,2-16 for household appliances
Operating altitude up to 5000 meters (Note.7)
Withstand 5G vibration test
LED indicator for power on
No load power consumption<0.3W
Over voltage category III
100% full load burn-in test
High operating temperature up to 70°C
High efficiency, long life and high reliability
3 years warranty
Applications: Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Household appliances
Model Number:LRS-100-24
Output Power:108W
Output Type:Single
Input Voltage:85 ~ 264VAC
Output Voltage:24V
Output Frequency:47 ~ 63Hz
Output Current:0~4.5A
Dimension:129*97*30mm (L*W*H)
Certification:TUV / CCC / CB / CE
Warranty:3 Years
Efficiency:90%
Feature:Low profile, low cost
Application:Various industrial applications
Protections:Short Circuit Overload Overvolt
Type:Single output
Features: Universal AC input / Full range
Withstand 300VAC surge input for 5 second
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Miniature size and 1U low profile
Compliance to IEC/EN 60335-1 (PD3) and IEC/EN61558-1,2-16 for household appliances
Operating altitude up to 5000 meters (Note.7)
Withstand 5G vibration test
LED indicator for power on
No load power consumption<0.3W
Over voltage category III
100% full load burn-in test
High operating temperature up to 70°C
High efficiency, long life and high reliability
3 years warranty
Applications: Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Household appliances
