1000w Switching Power Supply 0-12v 24v 36v 48v 60v 72v 90V 110V 220V 350V Voltage and Current Adjustable Digital Display(220V,0-60V 0-16.66A)

Industrial Power Suppl
1000w switching power supply AC-DC output 0-12v 13.8v 15v 24v 27v 36v 48v 60v 72v current and voltage adjustable smp
105C output capacitor
High efficiency, low operating temperature
Soft-start current can effectively reduce AC input impact
With short circuit and overload protection function
100% full load aging test
Install filter, minimum wave
Model specifications
S-1000-12
S-1000-13.5
S-1000-15
S-1000-24
S-1000-27
S-1000-48
DC output voltage (V)
12
13.5
15
twenty four
27
48
DC voltage adjustable range
0-12V
0-13.5V
0-15V
0-24V
0-27V
0-48V
Rated output current (A)
83
74
66.66
41.66
37
20.83
Output current range(A)
0~83
0~110
0~66.66
0~41.66
0~37
0~20.83
Waveform and Noise (mVp-p)
200
200
200
200
200
200
Inlet stability(%)
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
Load stability(%)
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
DC output power(W)
1000
1000
1000
1000
1000
1000
efficiency(%)
84
84
85
85.5
86.5
87
AC input voltage range
200~240VAC47~63Hz (220VAC or 110VAC, please select when ordering)
Input current
7A/230V
AC surge current
50A/230V
Leakage current
<;3.5mA/240VAC
Overload protection
105%-150% Type: Pulse Hiccup Shutdown Reset: Recovery
Overvoltage protection
13.8~16.2V
15.5~18.2V
18~21V
27.6~32.4v
31~36.5V
57.6~67.2V
High temperature protection
70°C cut-off output (0~50°C)
temperature coefficient
±0.03%/(0~50)
Setup time, rise time, hold time
1.5 seconds, 50 milliseconds, 20 milliseconds
vibration
10~500Hz, 2G10min,/1cycle. Cycle 60min, each axis
Pressure resistant
I/PO/P:1.5KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC
Isolation resistor
I/PO/P,I/P-F
