FindTape Microprismatic Sealed Reflective Conspicuity Tape [DOT-C2 10 yr.]: 2 in. width (Alternating 11 in. Red 7 in. White / Honeycomb Design) *20 strips

FindTape DOT-MS Microprismatic Sealed Reflective Conspicuity Tape is a high-quality DOT-compliant sealed micro-prismatic reflective conspicuity tape in an alternating red and white corner of the cube shape and can have retro-reflective performances up to 10 years. DOT-MS also meets the Federal Motor Carrier Safety Administration (FMCSA) and Federal Motor Vehicle Safety Standard (FMVSS) regulations requiring any trailer truck over 10,000 lbs and over 80-inches wide which are required to have a 2-inch wide alternating red and white pattern marked with DOT-C2 text.

This tape is far more visible from more than three times the distance when compared to a glass bead tape alternative. The smooth surface finish of the microprismatic seal features microprism technology that creates light reflections from man-made 3-point prisms that it is facing resulting in constant higher visibility for long distances and improved roadway safety for motor vehicles and other machines. The reflection returns up to 80% of the light in a cone shape resulting in amplified reflective properties and magnified visibility. The true-white color feature allows this to perfectly blend in with any white bodywork. With its construct, the tape is very durable and can survive repeated car washes and harsh winter weather conditions.

Please note that this tape is supplied on a clear film release liner wound around a 3-inch diameter core.

Coefficient of Retroreflection (candelas/lux/square meters)

Observation Angle | Entrance Angle | White | Red |
0.2° | -4° | 678 | 148 |
KEY_TAB | 30° | 452 | 92 |
0.5° | -4° | 351 | 71 |
KEY_TAB | 30° | 123 | 27 |

Coefficient of Retroreflection (candelas/lux/square meters)

Observation Angle | Entrance Angle | White | Red |
0.2° | -4° | 632 | 152 |
KEY_TAB | 30° | 397 | 88 |
0.5° | -4° | 345 | 75 |
KEY_TAB | 30° | 115 | 26 |

Remove the backing film release liner and firmly apply pressure to any surface that is clean, dry and free from grease. A squeegee is recommended to use when applying the tape as this will help ensure a sturdy and clean application.
