    12MP 4K USB Endoscope Camera Module AF3840x3104 Borescope Inspection Camera with 6LEDs Light for Product Vision

    Be the first to review this product...
    • Simple to Use: Just plug the endoscope into your phone or tablets USB portno Bluetooth, Wi-Fi, or extra power needed
    • Reliable & Durable: IP67 waterproof, 2 MP HD camera, and 8 adjustable LEDs for clear visibility, even in the dark
    • Wide Compatibility: Includes Type-C, Lightning, and micro USB adapters, working with iOS 9.0+ and Android 4.2+ systems
    • Exceptional Features: Capture photos and videos in 1920x1440 resolution, with side-by-side real-time image comparison for easy analysis
    • Certified Quality: EMC tested by an independent authority for excellent electromagnetic compatibility, ensuring reliable performance in various environments
    • Versatile: Features a 7.9 mm probe and 16.4 ft semi-rigid waterproof cable for stable, flexible use. Perfect for automotive inspection, snake drain hair removal tool, plumbing tools, industrial inspections, mechanical repairs, and HVAC maintenance
    +
    +
    Overview
    Specs
    Reviews
    avatar

    Any questions? Our AI beta will help you find out quickly.

    Try me now

    1.Main Parameters

    Product Name

    12MP 4K USB2.0 Camera Module

    Product Code

    WN-L2110.K301L

    Module Size

    Diameter 12.5mm

    Image Sensor

    1/3.6-inch IMX258 CMOS Sensor

    Max. Resolution

    3840H x 3104 V

    Pixel Size

    1.12*1.12µm

    Output Format

    MJPEG

    Field of View

    75°

    Audio Input

    Digital Two-way

    Focus Mode

    Autofocus

    Shutter Mode

    Electronic Rolling Shutter

    Output & Power Supply

    High Speed USB2.0

    Interface

    5PIN 1.0MM Socket

    Controllable Parameters

    Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Contrast, Exposure

    Supported OS

    UVC-compliant, Plug and Play for Windows, Android, Linux, Mac OS, etc.

    Connection Cable

    Default1.0 Meter USB Cable



    2.Supported Resolutions and Frame Rates



    Formats

    Resolutions

    Frame Rates

    MJPEG

    3840x3104

    15FPS

    3840x2160

    30FPS

    2592x1944

    30FPS

    2048x1536

    30FPS

    1920x1080

    30FPS

    1280x720

    30FPS

    800x600

    30FPS

    640x480

    30FPS



    3.PIN Definitions

    Pin No.

    Signal Names

    Descriptions

    1

    VCC

    5V power

    2

    DP

    USB2.0 Data+

    3

    DM

    USB2.0 Data-

    4

    GND

    GND

    5

    LED+

    LED+

    6

    LED-

    LED-

    4.Working Conditions


    Working Voltage

    DC 5V

    Working Current

    190mA

    Working Temperature

    -20°C ~ 60°C

    Storage Temperature

    -20°C ~ 85°C

    Humidity

    80 ~85%
    https://counter.pushauction.com/7d4818af-b9d4-43ef-9c72-def6910cb6b8/59251793-1670-4946-80da-4ababe9ccf59.jpg

    Easy to operate:

    Search for "UseePlus" in the app store or scan the QR code in the user manual to download the application, and then power the endoscope through the USB port

    Specifications:

    Camera diameter: 7.9mm
    Viewing angle: 70°
    Operating temperature: 32°F~113°F
    Camera resolution: 2 MP
    Focusing range: 2cm-10cm
    Camera temperature: 14°F~176°F

    What's in he Box:

    1 ×endoscope camera (with 16.4-foot semi-rigid C-type cable)
    1 × User manual
    1 × micro USB adapter
    1 × lightning port
    1 × accessories magnet
    1 × accessories hook
    1 × accessories mirror
    1 × accessories protective cap


    Product information

    Condition New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details.
    MPN Does Not Apply
    Brand Unbranded
    Features USB Connection
    Connectivity USB 2.0
    Maximum Photo Resolution 3840H x 3104 V
    Frame Rate 15 fps
