MSI MPG B650I EDGE WIFI AMD AM5 M-ITX Motherboard, 2x DDR5 ~64GB, 1x PCI-E x16, 2x M.2, 4x SATA, 2x USB2.0, 5x USB 3.2, 1x USB-C

MSI MPG B650I EDGE WIFI AMD AM5 M-ITX Motherboard, 2x DDR5 ~64GB, 1x PCI-E x16, 2x M. 2, 4x SATA, 2x USB 2.0, 5x USB 3.2, 1x USB-C CHIPSET AMD B650 CPU SUPPORT Supports AMD Ryzen 7000 Series Desktop Processors Socket AM5 MEMORY 2x DDR5, Maximum Memory Capacity 64GB Memory Support DDR5 6600+ (OC) /6400 (OC) /6200 (OC) /6000 (OC) /5800 (OC) /5600 (OC) /5400 (OC) /5200 (OC) /5000 (OC) /4800 (JEDEC) MHz Max.
overclocking frequency: 1DPC 1R Max. speed up to 6600+ MHz 1DPC 2R Max. speed up to 6000+ MHz Support Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO ONBOARD GRAPHICS 1x HDMI Support HDMI 2.1 FRL, maximum resolution of 4K 120Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. EXPANSION SLOT 1x PCI-E x16 slot PCI_E1 PCIe 4.0 supports up to x16 (From CPU) MULTI-GPU Supports AMD MULTI-GPU STORAGE 2x M. 2 slot M. 2_1 (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices M. 2_2 (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices 4x SATA 6G port RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M. 2 NVMe storage devices USB 2x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) LAN Realtek RTL8125BG 2.5G bps LAN PCB DIMENSION Mini-ITX 170mmx170mm
