Teltonika RUTX09000000 Model RUTX09 Industrial Cellular Router; Not for use in USA; for use in Europe (excluding Russia and Belarus), Middle East, Africa, Australia, APAC2, Brazil, and Malaysia

Teltonika RUTX09000000 Model RUTX09 Industrial Cellular Router; Not for use in USA; For use in Europe (excluding Russia and Belarus), Middle East, Africa, Australia, APAC2, Brazil, and Malaysia

Key Features:
- Not for use in USA; For use in Europe (excluding Russia and Belarus), Middle East, Africa, Australia, APAC2, Brazil, and Malaysia
- 4G (LTE) - Cat 6 up to 300 Mbps, 3G - Up to 42 Mbps
- Dual SIM With auto failover, backup WAN and other switching scenarios
- 4 x Ethernet ports with up to 128 port/tag-based VLA
Ns supported
- Global Navigation Satellite System for location services and time synchronization

Specifications

:

Mobile:
- Frequencies: 4G
(LTE-FDD): B1, B3, B5, B7, B8, B20, B28, B32
; 4G (LTE-TDD): B38, B40, B41
; 3G: B1, B3, B5, B8
- Mobile module: 4G (LTE) Cat 6 up to 300 Mbps, 3G Up to 42 Mbps
- SIM switch: 2 SIM cards with auto switch
- APN: Auto

Ethernet:
- WAN: 1 x WAN port 10/100/1000 Mbps
- LAN: 3 x LAN ports, 10/100/1000 Mbps

Network:
- Routing: Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing
- DHCP: Static and dynamic IP allocation, DHCP Relay

System Characteristics:
- CPU: Quad-core ARM Cortex A7, 717 MHz
- RAM: 256 MB, DDR3
- FLASH storage: 256 MB, SPI Flash

Power:
- Connector: 4-pin industrial DC power socket
- Input voltage range: 9 - 50 VDC
- Power consumption: 9 W Max

Physical Interfaces:
- I/O's: 1 x Digital Input, 1 x Digital Output on 4-pin power connector
- Ethernet: 4 x RJ45 ports, 10/100/1000 Mbps
- Power: 1 x 4-pin power connector
- Antennas: 2 x SMA for LTE, 1 x SMA for GNNS
- USB: 1 x USB A port for external devices

Other Specs:
- Casing material: Aluminum housing
- Dimensions (WxHxD): 4.52 x 1.74 x 3.74 inches
- Weight: 1 pound
