4K 8MP 180deg Panoramic Ultra Wide Viewing Angle Fisheye Eyeball Dome TVI CVI AHD Analog 4 in 1 CCTV Security Camera, 30ft IR Night Vision, Outdoor, Full Metal Housing, ONLY Compatible with 8MP DVR
- [(8MP Camera ONLY Works with 8MP 4K DVR)] - This 8MP 4K camera does NOT work with 5MP or lower resolution DVR, ONLY work with 4K 8MP DVR. This camera is 8 Megapixels high definition HD TVI/CVI/AHD/960H(1000 TVL), 30ft IR night vision range. It has a 1.8mm fisheye lens with 180 degree wide Field of View (FOV) to cover large areas.
- [(Compatible with Most Brand CCTV System)] - This camera model support 4 Video Format Outputs - Supports 4K 8MP HD-TVI, HD CVI, AHD and 960H 1000TVL. It works with TVI DVR, CVI DVR, AHD DVR and analog DVR. Default Video output is 8MP TVI Mode, compatible with all DVRs by switching video output mode. Video Mode must be switched according to your DVR type.
- [(DIP Switch)] - Use DIP Switch of your camera to switch to 4 video output format (TVI/CVI/AHD/CVBS). OSD(On Screen Display) menu can be accessed through "Iris+" icon Icon under DVR PTZ menu.
- [(Indoor and outdoor use weatherproof)] - This camera works indoor and order, come with IP66 weather-rated full
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
You must know before you buy:
1. This 4-in-1 security 180 wide angel camera requires a DVR for recording video. It supports 4K 8MP TVI DVR, HD CVI DVR, AHD DVR, and 960H DVR. It does not support IP NVR.
2. In TVI, CVI, AHD DVR Mode, camera resolution is 8MP. In CVBS (960H) mode, resolution is 1000TVL.
3. Camera resolution is 4K 8MP. If connect to 5MP, 4MP, 3MP, 1080P, 720P DVR or 960H DVRS, it won't work. Please make sure your DVR supports 1080P TVI/CVI/AHD signal input otherwise switch camera to Analog.
4. If need to remote view by App, customer needs to use the APP of DVR
Technical Parameters:
- 1/ 2.9" color CMOS sensor
- Resolution: 8MP
- 30ft IR Range
- TV System: NTSC
- Video Output: HD-TVI (1080P), (AHD/TVI/CVI/CVBS)
- Day &Night: Support (ICR)
- Frame Rate: 25fps (50HZ), 30fps (60Hz)
- Min illumination: 0.1 lux (LED ON) 0.01 lux(0-3 lux LED)
- S/N Ratio: >52dB (AGC off)
- Electronic Shutter: Auto 1/50s (1/60s)-1/ 100.000 s
- White Balance: Auto - Gain Control: Auto
- Weatherproof for indoor/outdoor
- Power Supply: DC12V 1000mA
4 in 1 video model, provides flexible for your security applications
HD-TVI/ CVI/AHD/960H technology delivers zero latency HD video over RG59 coax or any standard analog CCTV cabling up to 300'. With convenient DIP Switch control of settings over coax cabling, you can eliminate the need for a separate cable.
Note: This camera does not have recording or remote view feature, require DVR for recording, not wireless and do not support mobile view. Default mode is HD AHD, if you are using other type of DVR, like Analog DVR, please switch the video type follow the user manuals.
Package included:
1 x Dome camera
1 x Bag of mounting screws
1 x Installing Template
1 x Manual
1. This 4-in-1 security 180 wide angel camera requires a DVR for recording video. It supports 4K 8MP TVI DVR, HD CVI DVR, AHD DVR, and 960H DVR. It does not support IP NVR.
2. In TVI, CVI, AHD DVR Mode, camera resolution is 8MP. In CVBS (960H) mode, resolution is 1000TVL.
3. Camera resolution is 4K 8MP. If connect to 5MP, 4MP, 3MP, 1080P, 720P DVR or 960H DVRS, it won't work. Please make sure your DVR supports 1080P TVI/CVI/AHD signal input otherwise switch camera to Analog.
4. If need to remote view by App, customer needs to use the APP of DVR
Technical Parameters:
- 1/ 2.9" color CMOS sensor
- Resolution: 8MP
- 30ft IR Range
- TV System: NTSC
- Video Output: HD-TVI (1080P), (AHD/TVI/CVI/CVBS)
- Day &Night: Support (ICR)
- Frame Rate: 25fps (50HZ), 30fps (60Hz)
- Min illumination: 0.1 lux (LED ON) 0.01 lux(0-3 lux LED)
- S/N Ratio: >52dB (AGC off)
- Electronic Shutter: Auto 1/50s (1/60s)-1/ 100.000 s
- White Balance: Auto - Gain Control: Auto
- Weatherproof for indoor/outdoor
- Power Supply: DC12V 1000mA
4 in 1 video model, provides flexible for your security applications
HD-TVI/ CVI/AHD/960H technology delivers zero latency HD video over RG59 coax or any standard analog CCTV cabling up to 300'. With convenient DIP Switch control of settings over coax cabling, you can eliminate the need for a separate cable.
Note: This camera does not have recording or remote view feature, require DVR for recording, not wireless and do not support mobile view. Default mode is HD AHD, if you are using other type of DVR, like Analog DVR, please switch the video type follow the user manuals.
Package included:
1 x Dome camera
1 x Bag of mounting screws
1 x Installing Template
1 x Manual
