CMX Audio DA-240 Class D Power Amplifier, 240W, AC 115V to 230V/50-60Hz, Separate Speaker Outputs 8 Ohms/100V, Support 24V DC Operation, 1RU Height, Line Input with Separate Gain Control

CMX Audio DA-240 Class D Power Amplifier, 240W, AC 115V to 230V/50-60Hz, Separate Speaker Outputs 8 Ohms/100V, Support 24V DC Operation, 1RU Height, Line Input with Separate Gain ControlClass-D power amplifier is used for public address class-d amplifier or commercial power amplifier, 240W RMS, support 100V & 8 Ohm, 1U height, 19 inch rack mount and 85% efficiency.
Key Features: - Switching power technology digital power amplifier- Class-D PA power amplifier of minimum power consumption- 1RU height for less rack space and less heat generation- One channel power amplifier into 19" rack mount unit- Rated power output at 240W- Separate speaker outputs 8/100V- Balanced line input by phoenix connector- Line input with separate gain control- Output with high-cut filter on/off- Built-in auto standby feature on/off to save power consumption- Separate indicators for protection, clip, input and output- Complete short circuit, overload, high temp, clip and DC protection- Wide AC input switchable between 115V and 230V- Support 24V
DC operation systemSpecifications: -
Model: DA-240- Rated
Power Output: 240W-
Speaker Output: 100V & 8 Ohm-
Frequency Response: L/H Cut OFF 20Hz-20KHz (+1/-2dB) L/H Cut ON 70-10khZ ((+1/-3dB)-
Input: 0.775V, 0dBu, balanced phoenix connector by four channels-
Input Impedance: 10K-
S/N Ratio: more than 80dB-
Crosstalk: More than 60dB, 1KHz, Max output-
Power Consumption: 300W-
Power Supply: AC 115V to 230V, 50-60Hz- 24V
DC: With-
Overall Dimensions: 19 x 16.5 x 1.73 inches-
Weight: 9.2 pounds
