SDI Splitter 1 x 4, 1 in 4 Out SDI Distributor, Supports 3G-SDI/HD-SDI/SD-SDI Up to 1080P@60Hz
- 1 In 4 Out Splitting Function for Simultaneous DisplayThis SDI Splitter 1 x 4 takes one SDI signal and splittes it into four identical outputs, all displaying content simultaneously. This eliminates the need for multiple signal sources or complex wiring just connect your single SDI input to the SDI Splitter 1 x 4, and route the four outputs to your desired SDI monitors.
- Wide Compatibility with 3G-SDI/HD-SDI/SD-SDIThis SDI Distributor 1 in 4 out is highly versatile, supporting three key SDI signal types to fit most professional setups: SD-SDI: 270Mb/s bandwidth; HD-SDI: 1.485Gb/s bandwidth; 3G-SDI: 2.97Gb/s bandwidth. It handles resolutions up to Full HD 1080P@60Hz, making it suitable for both standard and high-definition SDI equipment.
- Long-Distance & Lossless Signal TransmissionThe SDI Splitter 1 x 4 excels at long-distance signal delivery, maintaining lossless quality even over extended cables. The maximum transmission distance varies by SDI signal type, matching professional
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
This SDI Splitter 1 x 4 is the ideal solution for expanding your SDI signal to multiple displays. The SDI Distributor 1 in 4 out is designed to split a single SDI input into four independent SDI outputs, enabling simultaneous display on four SDI monitors. Whether for broadcast studios, security setups, or commercial video systems, this SDI Splitter delivers stable, high-quality signal distribution every time. Whether youre using legacy SD-SDI cameras or modern 3G-SDI broadcast gear, this SDI Splitter 1x4 ensures seamless signal distribution without quality loss.
Note: 1. This SDI Splitter 1 x 4 only supports SDI signals; it does not work with RF, CVBS, AHD, TVI, or CVI signals. Always confirm your devices use SDI input/output to ensure compatibility with the SDI Splitter. 2. This SDI Distributor 1 x 4 does not support 4K SDI signals. Product Specifications1.
Frequency Bandwidth: 3Gbps2.
Input Connector: 1 x SDI (Female BNC) 3.
Output Connectors: 4 x SDI (Female BNC) 4.
Supported SDI Types: 3G-SDI, HD-SDI, SD-SDI5.
Maximum Resolution: 1080P@60Hz6.
Power Supply: DC 5V/1A7.
Dimensions (WxDxH): 70mm x 145mm x 25mm8.
Weight: 352gPackage Contents 1 x SDI Splitter 1 x 41 x Power Supply1 x User Manual
Note: 1. This SDI Splitter 1 x 4 only supports SDI signals; it does not work with RF, CVBS, AHD, TVI, or CVI signals. Always confirm your devices use SDI input/output to ensure compatibility with the SDI Splitter. 2. This SDI Distributor 1 x 4 does not support 4K SDI signals. Product Specifications1.
Frequency Bandwidth: 3Gbps2.
Input Connector: 1 x SDI (Female BNC) 3.
Output Connectors: 4 x SDI (Female BNC) 4.
Supported SDI Types: 3G-SDI, HD-SDI, SD-SDI5.
Maximum Resolution: 1080P@60Hz6.
Power Supply: DC 5V/1A7.
Dimensions (WxDxH): 70mm x 145mm x 25mm8.
Weight: 352gPackage Contents 1 x SDI Splitter 1 x 41 x Power Supply1 x User Manual
