Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
Alarm: 1 in, 1
out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic and speaker
SMD Plus
Image Sensor: 1/ 1.2" 8Megapixel progressive CMOS
Max.
Resolution: 3840 (H) x 2160 (V)
ROM/RAM: 128 MB/1 GB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s-1/100, 000 s
Min.
Illumination: 0.0005L ux@F 1.0
S/N Ratio: >56 dB
Illumination Distance: 40 m ( 131.2 ft)
Illuminator On/Off Control: Auto/Manual
Illuminator Number: 4 (Warm light)
Pan/Tilt/Rotation Range:
Pan: 0deg-360deg / Tilt: 0deg-90deg / Rotation: 0deg-360deg
Lens
Lens Type: Fixed-focal
Mount Type: M22
Focal Length: 2.8 mm; 3.6 mm
Max.
Aperture: F 1.0
Field of View:
2.8 mm: Horizontal 112deg x Vertical 61deg x Diagonal 131deg
3.6 mm: Horizontal 91deg x Vertical 50deg x Diagonal 106deg
Iris Type: Fixed
Close Focus Distance: 2.8
mm: 3.1 m( 10.2 ft) / 3.6 mm: 5.4 m( 17.7 ft)
Smart event
IVS: Abandoned object; missing object
Heat Map: Yes
Professional,
intelligent: IVS (Perimeter Protection); Face Detection; People Counting; Intelligent Search;
Alarm Event Network Network: RJ-45 (10/100
Base-T) Power Supply: 12V DC/PoE ( 802.3 af)
Power Consumption:
Basic: 2.2W (12 V DC); 2.8 W (PoE); Max. (H. 265+Face detection+LED on): 8.4 W (12V DC); 9.4 W (PoE)
Environment Operating Conditions: -40degC to +60degC (-40degF to +140degF)/Less than 95%
RH Storage Conditions: -40degC to +60degC (-40degF to +140degF)
Protection Grade: IP67
