2MP 1080P 180 Degree Surveillance CCTV Security Camera Fisheye Outdoor Analog TVI Camera (Quadbrid 4-in1 HD-CVI/TVI/AHD/BNC), 30ft Night Vision, Metal Housing

You must know before you buy: 1. This 4-in-1 security camera requires a DVR for recording video. It supports 1080P TVI DVR, HD CVI DVR, AHD DVR, and 960H DVR. It does not support IP NVR. 2. In TVI, CVI, AHD DVR Mode, camera resolution is 1080P. In CVBS (960H) mode, resolution is 1000TVL. 3. Camera resolution is 1080P. If connect to 720P DVR or 960H DVRS, it wont work. Please make sure your DVR supports 1080P TVI/CVI/AHD signal input otherwise switch camera to Analog. 4. If need to remote view by App, customer needs to use the APP of DVR
Technical Parameters: - 1/ 2.9" CMOS sensor-
Resolution: 1920x1080- 30ft
IR Range- TV System: NTSC-
Video Output: HD-TVI (1080P), (AHD/TVI/CVI/CVBS)-
Day &Night: Support (ICR) -
Frame Rate: 25fps (50HZ), 30fps (60Hz) -
Min illumination: 0.1 lux (LED ON) 0.01 lux(0-3 lux
LED)- S/N Ratio: >52dB (AGC off) -
Electronic Shutter: Auto 1/50s (1/60s)-1/ 100.000 s-
White Balance: Auto -
Gain Control: Auto- Weatherproof for indoor/outdoor-
Power Supply: DC12V 1000mA4 in 1 video model, provides flexible for your security applicationsHD-TVI/ CVI/AHD/960H technology delivers zero latency HD video over RG59 coax or any standard analog CCTV cabling up to
1600. With convenient DIP Switch control of settings over coax cabling, you can eliminate the need for a separate cable.
Note: This camera does not have recording or remote view feature, require DVR for recording, not wireless and do not support mobile view. Default mode is HD AHD, if you are using other type of DVR, like Analog DVR, please switch the video type follow the user manuals.
Package included: 1 x Dome camera1 x Bag of mounting screws1 x Installing Template1 x Manual
